KNITTER-SWITCH PCB Slide Switch DPDT Latching 50mA Gold over Nickel Plated Phosphor Bronze ASL 2D

KNITTER-SWITCH ASL 2D PCB Slide Switch DPDT Latching 50mA is an industrial-grade miniature slide switch designed for precise control in electronic and electrical systems. The switch features a two-pole double-throw (DPDT) contact configuration providing dual circuit functionality. Its latching operation mechanism ensures the switch maintains its contact position securely until manually changed, ideal for applications requiring dependable state retention.

The device mounts directly onto printed circuit boards (PCBs) using solder terminals for robust electrical connections. It supports a maximum contact current of 50mA at a DC voltage of 48 volts, meeting typical low-power control requirements.

Crafted using gold over nickel plated phosphor bronze for contacts and actuator materials, this switch presents excellent corrosion resistance and reliable electrical conductivity. The switch housing is compact, measuring 9.5 mm in length, 5 mm width, and 12.3 mm depth, suitable for dense electronic assemblies.

Designed for durability, the switch is rated for mechanical life of 60,000 operations and can operate reliably in temperature environments from -20 to 80 degrees Celsius. The product complies with RoHS environmental standards, ensuring non-toxic and environmentally friendly manufacturing.

DPDT contact configuration for dual circuit control. Latching operation maintains switch position when actuated. PCB mounting with solder terminal ensures stable connections. 50mA switch contact current at 48V DC operating voltage.

Gold over nickel plated phosphor bronze actuator material. Compact size suitable for miniature electronic assemblies. Durable up to 60,000 mechanical operations. Operates from -20°C to 80°C temperature range. RoHS compliant for environmental safety.

Manufactured in China to strict quality standards.

This micro miniature PCB Slide Switch is ideal for industrial automation, electronics manufacturing, control systems, and other precision electrical applications where reliable latching switching is required. It supports efficient assembly and improved production workflows due to its solder terminal mounting and low-profile form factor.
