Preci-Dip 803 Series Right Angle PCB Socket 12-Contact 2 Row 2.54 mm Pitch Solder 803-87-012-20-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 12 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- 12 electrical contacts arranged in 2 rows with 2.54 mm pitch spacing.
- Right angle orientation designed for PCB mounting and board-to-board connector applications.
- Constructed with black glass filled polyester housing for durability.
- Contacts are made of beryllium copper alloy with gold flash plating for reliable conductivity.
- Rated for a current of 12A and voltage of 150V operating in temperatures from -55°C to 125°C.
- Features solder termination type ensuring secure mechanical and electrical connection.
- Manufactured in Switzerland by Preci-Dip as part of the 803 series.
- Applicable for electronics manufacturing, industrial controls, and communication equipment.
Product Description
Preci-Dip 803-87-012-20-001101 is a right angle PCB socket from the 803 Series, engineered for seamless board-to-board connectivity. It features 12 female contacts arranged in 2 rows with a 2.54 mm pitch optimized for high-reliability electronic assemblies.
The socket housing is made from black glass filled polyester providing robust mechanical strength and excellent electrical insulation. Contacts are crafted from beryllium copper alloy with gold flash plating to ensure superior conductivity and corrosion resistance. Its solder termination facilitates secure assembly to printed circuit boards, making it suitable for intricate electronic and power connection requirements.
Rated for a current capacity of 12A and voltage of 150V, this connector reliably operates across a wide temperature range from -55°C to 125°C, accommodating demanding industrial and electronic environments. The right angle orientation supports compact PCB designs and facilitates efficient circuit layouts.
12 electrical contacts arranged in 2 rows with 2.54 mm pitch spacing. Right angle orientation designed for PCB mounting and board-to-board connector applications. Black glass filled polyester housing for mechanical durability and insulation.
Beryllium copper alloy female contacts with gold flash plating for reliable conductivity. Solder termination type ensures strong and stable connections. Operating voltage rated at 150V and current at 12A. Temperature range from -55°C minimum to 125°C maximum for versatile use.
Manufactured in Switzerland maintaining high quality standards.
This PCB Socket is ideal for use in electronics manufacturing, industrial control systems, communication devices, and other applications requiring durable, high-performance PCB connectors. The 803 series design ensures low profile and reliable mechanical and electrical connections tailored for modern electronic equipment production.
Explore additional Preci-Dip connectors and PCB components within the Electronics Components category at EnvMart for broader solutions to your PCB connector and electronics assembly needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 12A and a voltage of 150V.
It operates within a temperature range of -55°C to 125°C.
It features 12 female contacts arranged in 2 rows with a 2.54 mm pitch spacing.
The housing is constructed from black glass filled polyester, providing mechanical strength and insulation.
This model uses a solder termination type for secure mechanical and electrical connections.
It has a right angle orientation designed for PCB mounting and board-to-board applications.
The contacts are made of beryllium copper alloy with gold flash plating for reliable conductivity.
It is manufactured in Switzerland, maintaining high quality standards.
It is applicable for electronics manufacturing, industrial controls, and communication equipment.
This socket is classified as a board-to-board connector system.
The right angle orientation supports compact PCB designs and facilitates efficient circuit layouts.
Key features include 12 contacts, 2.54 mm pitch, right angle orientation, and a wide operating temperature range.
