Preci-Dip 803 Series Straight Surface PCB Socket 20-Contact 2 Row 2.54 mm Pitch Solder 803-87-020-10-012101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 20 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- The socket uses black glass filled polyester housing for durability.
- Designed for board-to-board connector systems with a straight orientation.
- Female contacts made from beryllium copper alloy with gold flash plating.
- Supports 12A current and 150V voltage ratings.
- Surface mount technology suitable for PCB assembly.
- Operational temperature range from -55°C to 125°C.
- 803 series features low profile straight headers.
- Contact and row pitch of 2.54 mm for standard spacing.
Product Description
Preci-Dip 803-87-020-10-012101 Straight Surface PCB Socket is a 20-contact, 2-row socket designed with a 2.54 mm pitch for solder termination on PCBs. It utilizes a robust black glass filled polyester housing to ensure mechanical stability and electrical insulation in demanding electronic assemblies.
This PCB Socket belongs to the 803 series known for low profile, straight headers, facilitating compact electronic designs. The socket’s female contacts are crafted from beryllium copper alloy, providing excellent conductivity, and are coated with gold flash plating to enhance corrosion resistance and ensure reliable electrical connections.
Designed for board-to-board connection systems with a straight orientation, the socket employs surface mount technology (SMT) that enables efficient manufacturing and high-precision insertion. It handles electrical loads up to 12A with a voltage rating of 150V, making it suitable for a wide range of industrial, telecommunications, and computing applications requiring secure and robust PCB connections.
Its operating temperature range spans from -55°C to 125°C, accommodating harsh environments across industrial and electronic sectors. Though this product does not carry specific international approval certifications, its Swiss manufacturing origin assures quality and precision.
The housing material is black glass filled polyester, enhancing durability. The contact material consists of beryllium copper alloy with gold flash plating. It supports solder termination for reliable electrical and mechanical connection.
The socket is designed with a 2-row, 20-contact configuration with 2.54 mm pitch. Mounting is surface type with straight orientation, compatible with board-to-board connector systems.
This socket is ideal for electronics manufacturing, communications equipment, industrial instrumentation, and other applications where high-performance PCB connectors are essential.
Explore the full range of Preci-Dip PCB connectors and sockets in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a current rating of 12A and a voltage rating of 150V.
The operational temperature range for this socket spans from -55°C to 125°C.
The housing is made from black glass filled polyester, while the female contacts are crafted from beryllium copper alloy with gold flash plating.
This model features a configuration of 20 contacts arranged in 2 rows.
It employs solder termination for reliable electrical and mechanical connections.
The pitch size for this socket is 2.54 mm, which is standard for many PCB applications.
This socket is designed for board-to-board connector systems with a straight orientation.
Yes, this model is designed for surface mount technology, making it suitable for PCB assembly.
This socket belongs to the 803 series, known for its low profile and straight headers.
This PCB socket is manufactured in Switzerland.
The contact gender of this socket is female.
It is suitable for a wide range of applications including industrial, telecommunications, and computing equipment requiring secure PCB connections.
