Preci-Dip 802 Series Straight Surface PCB Header 20 Contacts 2.54 mm Pitch 2 Row Shrouded 802-10-020-30-507101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 3.5A |
| Mount Type | Surface |
| Housing Material | Fibreglass Reinforced Polyethylene Terephthalate |
| Contact Material | Brass |
| Series | 802 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
Key Features
- Constructed with fibreglass reinforced polyethylene terephthalate housing for durability.
- Brass contacts plated with gold ensure reliable solder terminations.
- Rated for 3.5 A current and 150 V voltage for robust electrical performance.
- Operates in temperatures from -55°C to 125°C for versatility in applications.
- Designed for surface mount installation with straight orientation and male contacts.
- Shrouded contact protection to prevent accidental shorts and provide mechanical stability.
- Suitable for industrial and electronic assembly requiring precise, fixed contact PCB connectors.
Product Description
Preci-Dip 802-10-020-30-507101 PCB header is a straight surface mount connector designed for demanding electrical and electronic component assembly. This 802 Series header offers 20 brass contacts with gold plating arranged in two rows with a 2.54 mm pitch, ensuring strong solder connections and reliable signal integrity.
The housing is made from fibreglass reinforced polyethylene terephthalate, providing excellent mechanical strength and thermal resistance. It accommodates operating temperatures ranging from -55°C to 125°C, making it applicable in harsh industrial and manufacturing environments.
The connector supports up to 3.5 A current and 150 V voltage rating, suitable for robust power and signal transmission in various equipment. Its shrouded design offers enhanced protection for the contacts, preventing shorts and damage during handling and integration.
Mount type is surface mount, and the male contact gender facilitates straightforward PCB assembly. This connector is ideal for precise fixed contact connections in industrial electronics, manufacturing assembly lines, electronic instrumentation, and power distribution modules.
Fibreglass reinforced polyethylene terephthalate housing for robustness. Gold plated brass fixed male contacts ensure stable electrical connection. Surface mount type with straight orientation for easy PCB integration. Operating temperature range from -55°C to 125°C for versatile environments.
3.5 A current and 150 V voltage rating for dependable performance. Shrouded design prevents shorts and enhances mechanical protection. 20 contacts arranged in 2 rows with 2.54 mm pitch for accurate placement.
This Preci-Dip PCB header is manufactured in Switzerland, assuring high quality and precision engineering. It is commonly used in electronic assemblies, power connectors, industrial manufacturing, and equipment requiring reliable PCB Header connections.
Explore more electronic components and connectors in the Electronics & Electricals category on EnvMart for a broad range of compatible products from trusted brands such as Preci-Dip.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header is rated for a current of 3.5 A and a voltage of 150 V, making it suitable for robust electrical performance.
It operates within a temperature range of -55°C to 125°C, allowing for versatility in various applications.
The housing is made from fibreglass reinforced polyethylene terephthalate, and the contacts are made of brass with gold plating for reliable solder terminations.
This model features 20 contacts arranged in two rows with a pitch of 2.54 mm.
It is designed for surface mount installation, which facilitates straightforward PCB assembly.
The connector has male contacts, which are suitable for fixed contact connections in electronic assemblies.
Yes, it has a shrouded design that provides protection for the contacts, preventing accidental shorts and enhancing mechanical stability.
This model is manufactured in Switzerland, ensuring high quality and precision engineering.
The termination type for this model is solder, which is standard for PCB connections.
This header belongs to the 802 Series, which is designed for demanding electrical and electronic component assembly.
It is suitable for industrial electronics, manufacturing assembly lines, electronic instrumentation, and power distribution modules.
The orientation of this model is straight, which allows for easy integration into PCBs.
