Vishay 1-Element Bi-Directional Transient Voltage Suppressor 600 W Surface Mount DO-214AA Package SM6T18CA-E3/52
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.24mm |
| Length | 4.57mm |
| Model | SM6T18CA-E3/52 |
| Width | 3.94mm |
| Mount Type | Surface |
| Series | TRANSZORB TVS |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA (SMB) |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 32.5V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 17.1V |
| Maximum Reverse Stand-off Voltage Vwm | 15.3V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 123A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Bi-directional diode configuration provides comprehensive transient voltage suppression.
- Single element per chip design with 2-pin configuration for efficient circuit integration.
- Minimum breakdown voltage of 17.1 V and maximum reverse stand-off voltage of 15.3 V.
- High peak pulse power dissipation of 600 W ensures robust protection against transient surges.
- Clamping voltage of 32.5 V guarantees effective voltage limitation during spike events.
- Operational temperature range from -65°C to 150°C caters to diverse industrial applications.
- Compact DO-214AA (SMB) package dimensions with 4.57 mm length, 3.94 mm width, and 2.24 mm height.
- Automotive grade with AEC-Q101 certification for quality assurance in demanding environments.
Product Description
Vishay SM6T18CA-E3/52 1-Element Bi-Directional Transient Voltage Suppressor offers high reliability voltage spike protection for electronic circuits. Rated at 600 W peak pulse power dissipation, this device is housed in a low-profile surface mount DO-214AA (SMB) package suitable for space-constrained designs.
The bi-directional diode configuration enables the suppression of both positive and negative transient voltage spikes, preventing damage to sensitive components. Its precise minimum breakdown voltage of 17.1 V and maximum reverse stand-off voltage of 15.3 V provide effective circuit protection. The clamping voltage of 32.5 V ensures transient surges are reduced rapidly.
With an operating temperature range from -65°C to 150°C, this transient voltage suppressor withstands harsh industrial, automotive, and commercial environment demands. The component features a quick response time and low incremental surge resistance, essential for preserving circuit integrity during voltage surges.
The device meets automotive standard AEC-Q101, qualifying it for applications in automotive electronics, industrial machinery, laboratory instruments, telecommunications, and power supply units. Its compact dimensions (4.57 mm length, 3.94 mm width, 2.24 mm height) and surface mount capability facilitate easy PCB assembly and system integration.
Vishay's TRANSZORB TVS series ensures exceptional surge handling and clamping performance, making them ideal for protecting circuits from transient overvoltages caused by inductive load switching, lightning strikes, or electrostatic discharge events.
Bi-directional diode configuration supports comprehensive transient suppression. Single-element chip design with 2 pins simplifies integration. 600 W peak pulse power dissipation rating. Surface mount DO-214AA package suitable for high-density PCB designs.
Wide operating temperature range from -65°C to 150°C. Certified to automotive standard AEC-Q101 for rigorous application demands. Compact size ensures space-efficient PCB layouts. Designed for applications in automotive, industrial, telecommunications, and power electronics protection.
Explore EnvMart’s selection of electronic components for reliable transient voltage protection solutions.
Explore more products in our TVS Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is rated at 600 W, providing robust protection against transient surges.
The clamping voltage of this unit is 32.5 V, ensuring effective voltage limitation during spike events.
It has a length of 4.57 mm, a width of 3.94 mm, and a height of 2.24 mm, making it suitable for space-constrained designs.
The minimum breakdown voltage for this transient voltage suppressor is 17.1 V, providing effective circuit protection.
It features a bi-directional diode configuration, allowing for comprehensive suppression of both positive and negative transient voltage spikes.
This unit has a single element per chip design, which simplifies integration into circuits.
The transient voltage suppressor is certified to the automotive standard AEC-Q101, ensuring quality assurance for demanding environments.
This model has a pin count of 2, facilitating straightforward circuit integration.
The maximum peak pulse current is rated at 123 A, which is crucial for handling transient surges effectively.
It comes in a DO-214AA (SMB) package type, which is suitable for surface mount applications and high-density PCB designs.
