TE Connectivity DIN Rail Power Relay, 6V dc Coil, SPST, Through Hole Terminal PCN-106D3MHZ,000
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Height | 12.5mm |
| Length | 20mm |
| Model | PCN-106D3MHZ,000 |
| Width | 14mm |
| Mount Type | DIN Rail |
| Contact Material | Silver Nickel Alloy |
| Series | PCN |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -30°C |
| Terminal type | Through Hole |
| Standards/Approvals | RoHS |
| Coil Resistance | 300Ω |
| Coil Voltage | 6V dc |
| Coil Power | 200mW |
Key Features
- Coil voltage rated at 6V dc for efficient switching.
- Single Pole Single Throw (SPST) contact configuration for straightforward circuit control.
- DIN Rail mount type enabling easy installation in control panels.
- Through hole terminal type for secure electrical connections.
- Operating temperature range from -30°C to 70°C for versatile applications.
- Coil resistance of 300Ω ensuring sensitive coil performance.
- Coil power consumption of 200mW optimizing low power usage.
- Silver Nickel Alloy contact material ensuring durability and conductivity.
Product Description
TE Connectivity PCN-106D3MHZ,000 DIN Rail Power Relay is engineered with a 6V dc coil and a Single Pole Single Throw (SPST) contact configuration. Designed for industrial and commercial electrical automation, this relay is mounted on a DIN Rail, simplifying installation and integration in various control panels and machinery. The relay's through hole terminal type ensures firm and reliable connections.
Its compact size measuring 20mm in length, 14mm in width, and 12.5mm in height makes it suitable for installations with space constraints. The relay operates efficiently within a temperature range of -30°C to 70°C, making it adaptable for harsh environments.
The coil resistance stands at 300Ω, with a coil power consumption of only 200mW, indicating a sensitive coil that requires minimal power. Contacts are made with Silver Nickel Alloy, providing robust durability and excellent electrical conductivity. This model conforms to RoHS standards and features cadmium-free contacts, aligning with modern environmental regulations.
Typical industry applications include electrical automation, control systems, power distribution panels, industrial machinery control, and signal conditioning in manufacturing and laboratory environments.
Coil voltage rated at 6V dc for efficient switching. Single Pole Single Throw (SPST) contact configuration for straightforward circuit control. DIN Rail mount type enabling easy installation in control panels. Through hole terminal type for secure electrical connections.
Compact dimensions: 20mm length, 14mm width, 12.5mm height. Operating temperature range from -30°C to 70°C for versatile applications. Coil resistance of 300Ω ensuring sensitive coil performance. Coil power consumption of 200mW optimizing low power usage.
Silver Nickel Alloy contact material ensuring durability and conductivity. RoHS compliant and cadmium-free contacts supporting environmental safety. Explore EnvMart for a comprehensive selection of Power Relays and compatible electrical components for diverse industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a coil voltage rated at 6V dc, which allows for efficient switching.
It features a Single Pole Single Throw (SPST) contact configuration, suitable for straightforward circuit control.
This model is designed for DIN Rail mounting, facilitating easy installation in control panels.
It operates efficiently within a temperature range from -30°C to 70°C, making it adaptable for various environments.
The coil resistance is 300Ω, ensuring sensitive coil performance.
The coil power consumption is 200mW, optimizing low power usage.
The contacts are made from Silver Nickel Alloy, providing durability and excellent electrical conductivity.
The relay has compact dimensions of 20mm in length, 14mm in width, and 12.5mm in height.
Yes, it conforms to RoHS standards and features cadmium-free contacts, supporting environmental safety.
It uses a through hole terminal type, ensuring secure electrical connections.
Typical applications include electrical automation, control systems, power distribution panels, and industrial machinery control.
The power relay is manufactured by TE Connectivity, a recognized brand in the electronics and electrical industry.
