TRACOPOWER High Efficiency DC/DC Converter 3.3V DC 4.5A 36V DC Input 18V Input 15W Through Hole THN 15-2410N
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 88% |
| Length | 25.4mm |
| Model | THN 15-2410N |
| Depth | 9.9mm |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | THN 15N |
| Maximum Operating Temperature | 70°C |
| Package Type | Encapsulated |
| Operating temp. range | - 40°C to +85°C |
| Minimum Operating Temperature | -40°C |
| MTBF | 1670000h |
| Number of outputs | 1 |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 4.5A |
| Isolation Voltage | 1.6kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Smallest encapsulated 15W Converter! Ultra compact size | 1.0 x 1.0 x 0.4 |
Key Features
- High efficiency converter with up to 88% efficiency.
- Wide input voltage range from 18V to 36V DC.
- Compact shielded metal case measuring 25.4mm x 25.4mm x 9.9mm.
- Provides 1500 VDC isolation voltage for enhanced safety.
- Operates reliably from -40°C to +70°C ambient temperature.
- Integrated EN 55032 class A filter reduces electromagnetic interference.
- Remote On/Off control for flexible operation.
- Ideal for mobile equipment, instrumentation, and industrial electronics.
Product Description
TRACOPOWER THN 15-2410N is a high-performance DC/DC converter delivering 3.3V DC output at 4.5A with 15W maximum power. It supports a wide 2:1 input voltage range from 18V to 36V DC, suitable for various power supply conditions. This model features an encapsulated, shielded metal through-hole package with dimensions 25.4mm length, 25.4mm width, and 9.9mm depth, providing compact and robust installation options.
The unit integrates an EN 55032 Class A filter which minimizes electromagnetic interference, contributing to cleaner power output suitable for sensitive applications. Its high efficiency of up to 88% reduces heat generation and improves energy conservation. The device is designed to operate over a wide temperature range of -40°C to +70°C without power derating, ensuring reliable performance in harsh environments.
The THN 15-2410N offers 1500 VDC isolation between input and output, enhancing operational safety especially in industrial and communication equipment. Remote On/Off functionality and output voltage trimming options provide flexibility for system integration and customization. The converter's low no-load power consumption of 96 to 336 mW further optimizes energy use in idle states.
This product is suited for applications including mobile equipment, distributed power architectures, instrumentation, communication, and industrial electronics where space and power efficiency are critical. The encapsulated design not only ensures durability but also simplifies PCB mounting and thermal management.
High efficiency with up to 88% efficiency. Wide input voltage of 18V to 36V DC. Compact, shielded encapsulated metal package. Reliable operation from -40°C to +70°C ambient. 1500 VDC isolation voltage for safety. Remote On/Off control integrated.
Reduced no-load power consumption. Suitable for industrial, communication, and instrumentation uses. Output voltage trim for precise regulation. Choose TRACOPOWER DC/DC Converters from EnvMart for reliable, compact power conversion solutions meeting demanding industrial standards and applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model delivers an output voltage of 3.3V DC with a maximum output current of 4.5A, providing a maximum output power of 15W.
It supports a wide input voltage range from 18V to 36V DC, allowing it to operate under various power supply conditions.
The dimensions of this unit are 25.4mm in length, 25.4mm in width, and 9.9mm in depth, making it compact for installation.
This converter has a high efficiency rating of up to 88%, which helps reduce heat generation during operation.
It operates reliably within a temperature range of -40°C to +70°C, ensuring performance in harsh environments.
Yes, it offers a 1500 VDC isolation voltage between the input and output for enhanced safety in applications.
This model uses a through-hole mounting type, facilitating easy installation on PCBs.
It integrates an EN 55032 Class A filter, which minimizes electromagnetic interference, contributing to cleaner power output.
The unit has a low no-load power consumption ranging from 96 to 336 mW, optimizing energy use during idle states.
This converter is suitable for applications including mobile equipment, instrumentation, communication, and industrial electronics.
The maximum operating temperature for this model is 70°C, ensuring reliable performance under high temperature conditions.
The MTBF for the THN 15-2410N is 1,670,000 hours, indicating a long expected operational lifespan.
