Samtec Right Angle Through Hole Pin Header Unshrouded 14 Contacts 2 Row 2.54mm Pitch TSW-107-08-F-D-RA
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 400.0, 450.0, 500.0, 550.0V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 4.3A |
| Model | TSW-107-08-F-D-RA |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 1.52mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with phosphor bronze contacts plated in gold for reliable conductivity.
- Housing is made of durable polybutylene terephthalate material.
- Designed for through-hole mounting and solder termination.
- Suitable for board-to-board connector systems with male contact gender.
- Operates reliably from -55°C up to 125°C for diverse industrial applications.
- Supports voltages ranging from 400 V to 550 V and a current rating of 4.3 A.
- Tail pin length is 1.52 mm and mating pin length is 5.84 mm.
- Right angle orientation optimizes PCB space in assemblies.
Product Description
Samtec TSW-107-08-F-D-RA is a right angle through-hole pin header designed for industrial electronics and PCB assembly, featuring a 2-row, 14-contact configuration with a 2.54 mm pitch and unshrouded connector style.
The contacts are made of phosphor bronze with gold plating to ensure excellent electrical performance and corrosion resistance. Its housing material, polybutylene terephthalate, provides mechanical durability and heat resistance across an operating temperature range of -55°C to 125°C.
Intended for board-to-board connector systems, this pin header supports solder termination with male contacts and offers tail pin and mating pin lengths of 1.52 mm and 5.84 mm respectively, facilitating secure connections.
The rated voltage for this model covers 400 V to 550 V, with a current capacity of 4.3 A, making it suitable for power distribution and signal transmission in various electronic devices.
Designed to optimize PCB layouts, the right angle orientation allows compact placement in assemblies while ensuring reliable contact. The TSW series provides a comprehensive range of pin counts, terminal lengths, and ruggedizing plating features to meet diverse application needs.
Constructed with phosphor bronze contacts plated in gold for reliable conductivity. Durable polybutylene terephthalate housing material for mechanical strength and heat resistance. Supports through-hole solder termination and right angle mounting orientation.
14 unshrouded contacts arranged in 2 rows with 2.54 mm pitch spacing. Operating temperature range from -55°C up to 125°C ensures versatile application use. Voltage rating up to 550 V and current rating of 4.3 A suitable for industrial electronics.
Tail pin length: 1.52 mm; Mating pin length: 5.84 mm for secure connections. Unshrouded design allows easy access for soldering and assembly. Ideal for board-to-board connectors in electronic components, power distribution, and control systems.
Widely used in industrial, electronics manufacturing, control panels, and embedded system applications, the Samtec TSW-107-08-F-D-RA pin header supports reliable signal and power contacts. Explore EnvMart's PCB Connectors & Wire Housings for complementary components and related electronics solutions.
Explore more products in our PCB Pin Header category.
