Samtec TSW Series Right Angle Through Hole Pin Header, 5 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSW-105-08-F-S-RA

Samtec TSW-105-08-F-S-RA is a right angle through hole pin header designed for board-to-board connections in electronic assemblies. It features 5 male contacts arranged in a single row with a 2.54 mm pitch, suitable for various electronics manufacturing applications. The contact material is phosphor bronze with a gold plating that ensures excellent electrical conductivity and long-term reliability.

The housing is made from polybutylene terephthalate, providing mechanical stability and resistance to environmental stresses. This connector supports a wide operating temperature range from -55°C up to 125°C, making it suitable for industrial, commercial, and laboratory environments.

The pin header uses through-hole solder termination for robust mechanical retention on printed circuit boards and has a mating pin length of 5.84 mm and tail pin length of 1.52 mm. Rated for currents up to 4.3 A and voltages spanning 400 to 550 volts, it complies with standard PCB connector performance requirements.

The unshrouded design allows easy access for mating connectors or cables, and the right angle orientation facilitates compact PCB layouts and cost-effective board stacking solutions. This model includes special features that optimize cost and performance with varied plating and ruggedizing options, ideal for demanding electronic applications.

Features a 2.54 mm pitch suitable for standard PCB applications. Equipped with 5 male contacts in a single row for efficient connectivity. Utilizes gold-plated phosphor bronze contacts for enhanced conductivity and corrosion resistance.

Constructed with polybutylene terephthalate housing ensuring durability and stability. Designed for right angle orientation enabling versatile board-to-board connections. Termination by through-hole soldering ensures secure mount on PCBs.

Supports operating temperatures from -55°C to 125°C for broad environmental compatibility. Compatible with industry-standard contact system of 0.025 inch (0.635 mm) square post. Offers multiple voltage ratings including 400 V to 550 V for electrical flexibility.

Includes ruggedizing features and plating options to optimize cost and performance.

This Samtec TSW Series connector is well-suited for use in industrial controls, communications equipment, instrumentation, and other high-performance electronic systems. Its robust design and material quality ensure dependable operation in manufacturing, laboratory, and commercial applications.
