Norcomp 25 Way Straight 2.54 mm Pitch Through Hole D-Sub Connector with 4-40 Board Lock Male 172-E25-113R911
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500.0V |
| Brand | Norcomp |
| Orientation | Straight |
| Current | 5A |
| Model | 172-E25-113R911 |
| Mount Type | Through Hole |
| Housing Material | Steel |
| Contact Material | Brass |
| Series | 172 |
| Mounting Hardware | 4-40 Board Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 100°C |
| Minimum Operating Temperature | -50°C |
| Shell | Steel, Nickel plated |
| Plating | Gold flash on entire contact |
| Pitch | 2.54mm |
| Insulator | Glass-filled thermoplastic. (260°C process temp) |
| Contact Plating | Gold Flash |
| Number of Contacts | 25 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | D |
| Machined contacts | Male pins - Brass | Female pins - Brass |
Key Features
- The connector supports 25 contacts with a current rating of 5A.
- It features a straight orientation and through-hole mount type for secure installation.
- Housing is constructed from steel with nickel plating for durability and corrosion resistance.
- Contacts are brass with a gold flash plating to ensure optimal conductivity and corrosion protection.
- Operating temperature range is from -50°C to 100°C, suitable for various industrial applications.
- Termination type is solder, facilitating strong and durable electrical connections.
- The connector includes 4-40 board lock mounting hardware for stable attachment.
- Pitch between contacts is 2.54 mm, allowing standard spacing compliant with industry applications.
Product Description
Norcomp 172-E25-113R911 is a 25-way straight D-Sub connector with a 2.54 mm pitch designed for through-hole PCB mounting. This male connector operates at 500V with a current capacity of 5A, suitable for diverse electronic and power connection needs in industrial, laboratory, manufacturing, and commercial environments.
The connector features a robust steel housing with nickel plating to enhance durability and corrosion resistance. The contacts, made of brass plated with gold flash, provide reliable electrical conductivity and longevity. Its temperature operation range from -50°C to 100°C ensures performance stability across demanding conditions.
The termination method is solder, facilitating secure and strong electrical connections on printed circuit boards. It is equipped with a 4-40 board lock hardware that ensures the connector remains securely mounted during operation. The pitch of 2.54 mm between contacts is standard for such connectors, allowing compatibility with a wide range of applications.
Manufactured in Taiwan, Province Of China, the product adheres to reliable quality standards without specific certification approvals. It is ideal for use in electronic components assemblies, power connections, and equipment where secure and precise connector solutions are needed.
The connector supports 25 contacts with a current rating of 5A. It features a straight orientation and through-hole mounting style. Contact material is brass with gold flash plating for superior conductivity. Housing consists of steel with nickel plating for toughness.
Operational temperature ranges from -50°C to 100°C. Mounting hardware includes 4-40 board lock for secure installation. Solder termination ensures reliable electrical connection. Voltage rating of 500V accommodates diverse applications.
Pitch of 2.54 mm between pins for industry-standard spacing. Manufactured in Taiwan, Province Of China. Explore more Norcomp D-Sub Connectors and related electronic components on EnvMart to find solutions suitable for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This D-Sub connector has a current rating of 5A.
The voltage rating for this model is 500V.
The pitch between the contacts is 2.54 mm, which is standard for such connectors.
The housing is made from steel with nickel plating, while the contacts are brass with gold flash plating.
The operating temperature range is from -50°C to 100°C.
This connector features a through-hole mount type for secure installation.
The termination type for this connector is solder, ensuring strong electrical connections.
The connector includes 4-40 board lock mounting hardware for stable attachment.
This model supports 25 contacts.
The connector features male contacts.
This connector is manufactured in Taiwan, Province Of China.
This connector is suitable for various industrial applications, including electronic components assemblies and power connections.
