Norcomp Panel Mount D-Sub Connector Female 3 Contacts 40A 6.85 mm Pitch 1.0 kV Steel Housing 680M3W3203L401

Norcomp 680M3W3203L401 is a high-quality panel mount D-Sub Connector featuring 3 female contacts designed to support current loads up to 40A and voltage ratings up to 1.0 kV. The connector uses a steel housing with nickel plating to offer mechanical strength and corrosion resistance, ideal for industrial and electronic applications.

The connector's glass-filled thermoplastic insulator is black in color and aids in high dielectric performance. Termination is by solder, ensuring reliable attachment to PCBs or wiring assemblies. With an operating temperature range from -55°C to 155°C, this connector is suitable for use in harsh environmental conditions encountered in industrial machinery, automation systems, and power distribution panels.

This model is part of the 680M series, which supports mixed contacts for signal and power, enabling versatile connectivity solutions. The contact plating is a gold flash finish providing excellent conductivity and durability over repeated mating cycles. Contact materials consist of machined copper alloy engineered for robust electrical performance.

The pitch of 6.85 mm is standard for this series, maintaining compatibility with mating assemblies and ensuring precise signal transmission. Typical industrial use cases include electronic instrumentation panels, automation controls, power supply interconnections, and machinery control systems.

The connector includes 3 female contacts for robust signal transmission. Panel mount type ensures stable fixation on control panels. High current carrying capacity of up to 40 amperes. Constructed with a steel housing for durability and nickel plating for corrosion resistance.

Glass-filled thermoplastic black insulator enhances electrical insulation and heat resistance. Rated for voltage up to 1.0 kV suitable for demanding electrical environments. Operating temperature range from -55°C to 155°C supports harsh industrial conditions.

Solder termination type facilitates secure and stable connection to PCB. Gold flash plating on contacts ensures superior conductivity and resistance to wear. Contact material composed of machined copper alloy combining performance and reliability.

Designed in compliance with industry standard 680M series for mixed signal and power contacts. Explore the wide range of Norcomp connectors at EnvMart for reliable electronic component solutions.
