KEMET R46 Film Capacitor X2 ±20 % 330 nF 560 V DC 275 V AC Through Hole R46KI333040P2M

Free Delivery in India | Lowest Global Shipping Charges

KEMET R46 Film Capacitor X2 ±20 % 330 nF 560 V DC 275 V AC Through Hole R46KI333040P2M

Name: KEMET R46 Film Capacitor X2 ±20 % 330 nF 560 V DC 275 V AC Through Hole R46KI333040P2M
Brand: KEMET
SKU: 95449
Price: 0.58 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	Bulgaria
Capacitance Range	0.01 - 10 μF
Display	screen
Brand	KEMET
Height	17.5mm
Length	18mm
Model	R46KI333040P2M
Packaging	Bag
Width	6mm
Mount Type	Through Hole
Series	R46
Maximum Operating Temperature	110°C
Tolerance	±20 %
Capacitance	330nF
Minimum Operating Temperature	-40°C
Climatic category	40/110/56
Terminal type	Radial
Dissipation Factor	0.1%
Lead Length	30mm
Pin Count	2
Rated AC Voltage	275V ac
Rated DC Voltage	560V dc
Lead Pitch	15mm
Lead Diameter	0.6mm
Suppression Class	X2
Capacitance tolerance	±20%, ±10%
Lead Spacing	10.0 - 37.5 mm

Key Features

Capacitance value of 330 nF with ±20 % tolerance.
Rated for 560 V DC and 275 V AC operating voltages.
Operating temperature range from -40°C to 110°C.
Radial terminal type with 30 mm lead length and 15 mm lead pitch.
Constructed from metallized polypropylene film encapsulated with self-extinguishing resin.
Features self-healing properties ensuring durability and reliability.
Complies with X2 suppression class for EMI suppression.
Lead diameter of 0.6 mm and lead spacing range from 10.0 to 37.5 mm.

Product Description

KEMET R46KI333040P2M Film Capacitor is a high-quality X2 class film capacitor designed for effective EMI suppression in electronic circuits. It features a capacitance of 330 nF with a ±20 % tolerance, supporting a rated DC voltage of 560 V and AC voltage of 275 V. This capacitor uses through-hole mounting with radial terminals, suitable for reliable and robust PCB assembly.

The capacitor is constructed with metallized polypropylene film encapsulated in self-extinguishing resin to enhance safety and longevity. It operates efficiently across a broad temperature range from -40°C to 110°C, making it suitable for diverse industrial and commercial electronic applications.

With a lead pitch of 15 mm and lead length of 30 mm, it provides convenient installation and connectivity. Self-healing characteristics improve performance stability under electrical stress, while the X2 suppression class indicates its capability to handle line-to-line interference electromagnetic noise.

Physical dimensions are compact with 18 mm in length, 6 mm in width, and 17.5 mm in height, optimized for space-constrained electronics applications. The lead diameter measures 0.6 mm, and the capacitance range across the R46 series extends from 0.01 to 10 μF, offering versatile options for designers.

This film capacitor is ideal for use in power electronics, industrial machinery, and EMI filtering in HVAC systems, manufacturing equipment, and electronic power supplies. Its reliable performance supports compliance with various non-automotive industrial standards.

Capacitance value of 330 nF with ±20 % tolerance. Rated for 560 V DC and 275 V AC operating voltages. Operating temperature range from -40°C to 110°C. Radial terminal type with 30 mm lead length and 15 mm lead pitch. Constructed from metallized polypropylene film encapsulated with self-extinguishing resin.

Features self-healing properties ensuring durability and reliability. Complies with X2 suppression class for EMI suppression. Package: Bag with pin count of 2. Dimensions: 18 mm length, 6 mm width, and 17.5 mm height. Lead diameter of 0.6 mm and lead spacing range from 10.0 to 37.5 mm.
