Samtec Right Angle Surface Pin Header 6 Contacts 2.54 mm Pitch 1 Row Unshrouded TSM-106-01-L-SH

Samtec TSM-106-01-L-SH is a right angle surface mount pin header featuring 6 male contacts arranged in a single row with a 2.54 mm pitch. Its unshrouded design allows for easy and secure mating with compatible sockets, suitable for various electronic and electrical industrial applications.

The contacts are made from phosphor bronze, plated with gold to ensure optimal conductivity and resistance to corrosion, while the housing utilizes liquid crystal polymer, a material known for its stability and durability under mechanical and thermal stress.

Designed specifically for surface mount technology, the header supports a maximum current of 4 amperes and withstands voltages up to 475 volts. It operates reliably within a temperature range spanning from -55°C to 125°C, making it suitable for harsh industrial environments.

The contact system employs a .025 inch (0.635 mm) square post, providing a firm mechanical and electrical connection. Mounting is surface type with solder termination, enabling easy integration into printed circuit boards using mixed technology assembly processes.

Applications for this pin header include board-to-board and wire-to-board connections within industrial electronics, communication equipment, and other manufacturing contexts requiring robust and high-reliability electrical connectors.

Features a phosphor bronze contact material with gold plating for reliable conductivity. Housing is made from liquid crystal polymer ensuring durability under stress. Designed for surface mount applications with a right angle orientation.

Accommodates a current rating of 4A and operating voltage of 475V. Operates in a temperature range from -55°C to 125°C. Contact system uses .025" (0.635 mm) square post for secure connections. Suitable for board-to-board and wire-to-board connector systems.

Unshrouded termination type with solder mounting for mixed technology processing.

Choose Samtec TSM Series for high performance PCB connectivity solutions optimized for long life and high mating cycles. Explore more PCB Pin Header products at EnvMart for industrial-grade electronic component needs.
