Norcomp MICRO-D 15 Way Right Angle 1.27 mm Pitch Through Hole D-Sub Connector with Board Lock Male 381-015-112L565
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 500V |
| Brand | Norcomp |
| Orientation | Right Angle |
| Current | 1A |
| Model | 381-015-112L565 |
| Mount Type | Through Hole |
| Housing Material | Steel |
| Contact Material | Copper Alloy |
| Series | MICRO-D |
| Mounting Hardware | Board Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | High Density |
Key Features
- Compact micro-miniature design at one-third the size of standard D-Sub connectors.
- Right angle orientation with board lock for enhanced PCB retention.
- High density connector with 15 male contacts rated at 1 A current.
- Steel housing with gold-plated copper alloy contacts ensuring durability and conductivity.
- Supports up to 500 V operating voltage with solder termination type.
- Operating temperature range from -55°C to 85°C for versatile industrial use.
- Metal-to-metal interface provides improved grounding and shielding performance.
- Includes female screwlocks for secure mounting and compatibility with commercial products.
Product Description
Norcomp 381-015-112L565 MICRO-D 15 Way Right Angle 1.27 mm Pitch Through Hole D-Sub Connector with Board Lock Male is engineered for high-density electronic interface applications requiring compactness and reliability.
This MICRO-D 380 and 381 series connector is approximately one third the size of a standard D-Sub connector, offering space-saving benefits for circuit board designs. The steel housing combines robustness with corrosion resistance, while gold-plated copper alloy contacts guarantee high conductivity and long service life.
The right angle orientation and board lock mount type enhance mechanical retention on PCBs, preventing dislodgement during operation. It accommodates 15 male contacts rated for 1 amp current and supports an operating voltage of up to 500 volts.
Operating temperature ranges from -55°C to 85°C, making it suitable for demanding environments including industrial electronics, telecommunications, and instrumentation. Installation uses solder termination for secure electrical connections.
The metal-to-metal interface provides excellent grounding and shielding, reducing electromagnetic interference and improving signal integrity. Additionally, female screwlocks ensure a secure mounting connection, suitable for commercial and industrial standards.
Compact micro-miniature D-Sub connector at one-third size of standard connectors. 15 way high-density male contacts with 1 A current rating. Right angle, through hole mount with board lock for secure PCB installation. Steel housing with gold-plated copper alloy contacts for durability and conductivity.
Supports 500 V operating voltage and temperature range -55°C to 85°C. Metal-to-metal interface offers superior grounding and shielding performance. Includes female screwlocks for secure mounting compliance with industry standards.
This MICRO-D D-Sub connector series is ideal for electronics manufacturing, industrial systems, telecommunications, and other applications requiring compact, reliable I/O connections with robust mechanical retention.
Explore more Norcomp D-Sub Connectors on EnvMart for specialized industrial and commercial electronic needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 1 amp for its 15 male contacts.
It supports a maximum operating voltage of 500 volts.
The operating temperature range is from -55°C to 85°C.
This unit uses solder termination for secure electrical connections.
The pitch of the contacts is 1.27 mm.
The housing is made of steel, and the contacts are made from gold-plated copper alloy.
It features 15 male contacts.
This model supports through hole mounting with a board lock for enhanced retention.
It is suitable for industrial electronics, telecommunications, and instrumentation applications.
Yes, it includes female screwlocks for secure mounting.
The connector has a right angle orientation.
The country of origin for this connector is Taiwan.
