Panasonic Power Relay ALQ324 PCB Mount, 24V DC Coil Voltage, 10A Switching Current, SPST Contact Configuration
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ324 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS, VDE |
| Coil Resistance | 2.9kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 30V ac |
| Coil Power | 200mW |
| Switching Power | 150W |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact size ideal for PCB mounting and space-constrained applications.
- Coil voltage of 24V DC with coil resistance of 2.9kΩ and power of 200mW.
- Switching current capacity of 10A with silver alloy contacts for durability.
- Wide operating temperature range from -40°C to 85°C for reliable performance.
- High insulation resistance and surge voltage capacity of 8000 V.
- Contact resistance is low at 100mΩ ensuring efficient signal switching.
- Suitable for industrial, appliance, and power supply applications.
- Meets RoHS and VDE standards for safety and environmental compliance.
Product Description
Panasonic ALQ324 is a power relay designed for PCB mounting applications, offering a coil voltage of 24V DC and a robust switching current of 10A with SPST contact configuration. This compact relay series provides reliable and high-performance switching suitable for a variety of industrial and commercial uses.
The relay's coil resistance is 2.9kΩ and coil power consumption is a minimal 200mW. It operates efficiently over a temperature range from -40°C to 85°C, ensuring dependable performance in challenging environments. The contact material comprises silver alloy, delivering excellent conductivity and durability with a low contact resistance of 100mΩ.
This ALQ series relay supports a maximum switching power of 150W and can switch both AC and DC voltages up to 30V. It is built to withstand high surge voltages of 8000 V and breakdown voltages of 4000 V, providing additional reliability and electrical isolation.
Its compact size - with dimensions of 20mm length, 10mm width, and 15.6mm height - makes it ideal for dense PCB layouts in appliances such as refrigerators, cooking ovens, washing machines, air conditioners, motor controls, robotics, and power supplies.
Compact design for efficient PCB installation. Wide ambient temperature range from -40°C to +85°C. Reliable switching with 10A capacity and silver alloy contacts. High surge and breakdown voltage ratings ensure robust operation.
Compliant with RoHS and VDE standards, ensuring environmental safety and quality. Low coil power consumption at 200mW for energy efficiency. Suitable for applications in industrial equipment, household appliances, and automation systems.
High insulation resistance enhances reliability and lifespan. Simplifies designs requiring safe and compact power relay solutions. Manufactured in Thailand with quality assurance. Explore more Panasonic Power Relays and related electrical components at EnvMart for your industrial, commercial, and electronics design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 24V DC.
It has a maximum switching current capacity of 10A.
The relay measures 20mm in length, 10mm in width, and 15.6mm in height.
This model features an SPST (Single Pole Single Throw) contact configuration.
It operates efficiently over a temperature range from -40°C to 85°C.
The contacts are made from silver alloy, providing excellent conductivity and durability.
The coil resistance is 2.9kΩ.
The coil power consumption is 200mW.
It can withstand high surge voltages of up to 8000 V.
This relay meets RoHS and VDE standards for safety and environmental compliance.
The maximum switching power is 150W.
Yes, it can switch both AC and DC voltages up to 30V.
