Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPST ALQ312
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ312 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS, VDE |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 30V ac |
| Coil Power | 200mW |
| Switching Power | 150W |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact size with high switching capacity for efficient performance.
- Coil voltage rated at 12V DC with a coil resistance of 720 ohms.
- Switching current capacity of 10A supporting switching power of 150W.
- Operating temperature range from - 40°C to +85°C suitable for varied environments.
- Contact material made of silver alloy ensuring reliable conductivity.
- High surge voltage tolerance of 8000 V for durability under stress.
- High breakdown voltage of 4000 V to maintain insulation integrity.
- Mount type designed for PCB with PCB pin terminals for secure installation.
Product Description
Panasonic ALQ312 PCB Power Relay is a high-quality power relay designed for printed circuit board (PCB) mounting applications. This relay features a 12V DC coil and supports a maximum switching current of 10A, making it ideal for a range of electrical and automation uses. Its single pole single throw (SPST) contact configuration allows straightforward switching operations.
The ALQ312 model is part of the ALQ series known for their compact size yet robust operating power and reliability under demanding conditions. It is suitable for industrial and household appliances such as refrigerators, cooking ovens, washing machines, air conditioners, and motor controls.
This relay operates effectively between ambient temperatures of - 40°C to +85°C and offers high resistance to surges up to 8000 V and breakdown voltage of 4000 V, ensuring long-term stability and performance. The contact material is silver alloy, which provides excellent conductivity and low contact resistance of 100mΩ for dependable switching.
Designed with PCB pin terminals for easy mounting, the relay’s physical dimensions are compact with a length of 20mm, height of 15.6mm, and width of 10mm. Coil power consumption is low at 200mW, enhancing energy efficiency in circuits.
Applications extend across various industrial and commercial sectors including automation, manufacturing, HVAC systems, and power supplies, where compact, reliable switching relays are essential.
Compact size with high switching capacity for efficient performance. Coil voltage rated at 12V DC with coil resistance of 720Ω. Switching current capacity of 10A supporting switching power of 150W. Operating temperature range from - 40°C to +85°C suitable for varied environments.
Contact material made of silver alloy ensuring reliable conductivity. High surge voltage tolerance of 8000 V for durability under stress. High breakdown voltage of 4000 V to maintain insulation integrity. Mount type designed for PCB with PCB pin terminals for secure installation.
Contact resistance maintained at 100 milliohms for efficient switching. Compact dimensions: length 20mm, height 15.6mm, width 10mm.
Explore EnvMart’s extensive range of electrical and automation components to find quality Panasonic Power Relays and other industrial-grade products for your projects and operations.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for this relay is 10A.
The coil voltage is rated at 12V DC, with a coil resistance of 720 ohms.
The relay has a length of 20mm, a height of 15.6mm, and a width of 10mm.
This model features a single pole single throw (SPST) contact configuration.
The relay operates effectively between -40°C and +85°C.
The contact material is made of silver alloy, ensuring reliable conductivity.
It has a high surge voltage tolerance of 8000 V.
The breakdown voltage for this relay is 4000 V, which helps maintain insulation integrity.
The contact resistance is maintained at 100 milliohms.
The coil power consumption is low at 200mW.
This relay complies with RoHS and VDE standards.
It is designed for PCB mounting with PCB pin terminals for secure installation.
