Panasonic PCB Power Relay 5V dc Coil 5A Switching Current SPST APAN3105

Panasonic APAN3105 PCB Power Relay is engineered for reliable operation in industrial equipment, office devices, programmable controllers, test instruments, and temperature control systems. Its 5V dc coil and SPST contact configuration deliver a switching current of up to 5A with a switching power rating of 150W, making it suitable for moderate power switching applications requiring high durability.

The relay features a low operating power coil consuming only 110 mW, which extends overall system efficiency while maintaining a coil resistance of 227Ω to ensure stable energizing characteristics. Its gold plated contacts provide excellent conductivity and wear resistance, contributing to a long-lasting switching life and low contact resistance of 30 mΩ.

Designed for PCB mounting, the relay’s compact dimensions of 20mm by 12.5mm by 5mm allow for high-density mounting on printed circuit boards in constrained spaces. It supports a broad operating temperature range from -40°C to 90°C, making it dependable under harsh industrial environments. The relay also complies with RoHS and cULus safety and environmental standards, endorsing its quality and regulatory adherence.

Installed in various applications including industrial automation, machinery controls, and measurement equipment, the Panasonic APAN3105 relay ensures precise and efficient switching performance. It maintains a reinforced insulation meeting IEC61010 standards, enhancing its suitability for demanding and sensitive electrical applications.

Its robust technical features and compact design make it a versatile relay choice for engineers and system integrators requiring dependable switching solutions. The relay is manufactured in China under stringent quality control, assuring consistent performance and reliability.

Compact design with PCB mount type for easy integration. Switching power rated at 150W suitable for varied applications. Gold plated contacts ensure reliable and low-resistance switching. Wide operating temperature range from -40°C to 90°C.

Complies with RoHS and cULus standards for safety and environmental compliance. Low coil power consumption of 110 mW improves energy efficiency. Coil resistance of 227Ω for stable and consistent performance. Coil voltage of 5V dc compatible with industrial control circuits.

Typical relay dimensions: 20mm length, 12.5mm height, and 5mm width. Contact resistance as low as 30 mΩ to minimize power loss. Explore EnvMart for a wide range of industrial relays and electrical components to meet your system design and maintenance needs.
