Panasonic PCB Power Relay 24V DC Coil, 10A Switching Current, SPDT ALQ124
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ124 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, RoHS |
| Coil Resistance | 1.4kΩ |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 30V ac |
| Coil Power | 400mW |
| Switching Power | 150W |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact size suitable for PCB mounting applications.
- Operates reliably between -40°C and +85°C ambient temperature.
- High surge voltage resistance up to 8000 V for electrical robustness.
- Silver alloy contact material ensures excellent conductivity and durability.
- Switching power rating of 150W supports a variety of industrial needs.
- Low coil power consumption at 400mW enhances energy efficiency.
- Contact resistance is minimized to 100mΩ for optimal performance.
- Meets VDE and RoHS standards for safety and environmental compliance.
Product Description
Panasonic ALQ124 PCB Power Relay is a compact, high-performance power relay designed for robust and reliable operation in various industrial and commercial applications. The relay features a 24V DC coil and a Single Pole Double Throw (SPDT) contact configuration, making it suitable for a diverse range of switching tasks.
This relay can handle a switching current of up to 10A and supports switching voltages of 30V DC and 30V AC, with a power rating of 150W, suitable for appliances, white goods, energy equipment, lighting, and industrial devices.
Manufactured with a silver alloy contact material, this relay offers high conductivity and durability, supported by a low contact resistance of 100mΩ. The compact dimensions (20mm length, 10mm width, and 15.6mm height) make it ideal for PCB mounting, and it uses PCB pins for terminal connections.
The ALQ124 relay operates effectively in harsh environments with an operating temperature range from -40°C to +85°C. It features high insulation resistance, a robust coil resistance of 1.4kΩ, and a coil power consumption of only 400mW to optimize energy efficiency.
Additional electrical robustness is provided by its high breakdown voltage of 4000 V and surge voltage resistance up to 8000 V, ensuring reliable performance under electrical stress.
This relay meets important industry standards including VDE and RoHS, guaranteeing safety and environmental compliance. Compact design with high switching capacity. Wide operating temperature range from -40°C to +85°C. High surge and breakdown voltage ratings.
Silver alloy contacts for reliability and conductivity. Low coil power consumption at 400mW. PCB mount type with PCB pin terminals. Meets VDE and RoHS standards.
Common applications include refrigerators, cooking ovens, washing machines, air conditioners, motor controls, robotics, and power supply systems. This relay ensures dependable power switching in demanding conditions across industrial, commercial, and residential environments.
Explore more Power Relay products from trusted brands in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay can handle a switching current of up to 10A.
The coil voltage for this model is 24V DC.
It operates effectively within an ambient temperature range of -40°C to +85°C.
The relay features a Single Pole Double Throw (SPDT) contact configuration.
The dimensions of this relay are 20mm in length, 10mm in width, and 15.6mm in height.
The contacts are made from silver alloy, which ensures excellent conductivity and durability.
It has a high breakdown voltage of 4000 V and a surge voltage resistance of up to 8000 V.
The coil power consumption is 400mW, which enhances energy efficiency.
This relay meets VDE and RoHS standards for safety and environmental compliance.
The contact resistance is minimized to 100mΩ for optimal performance.
Common applications include refrigerators, cooking ovens, washing machines, air conditioners, and motor controls.
This model is designed for PCB mounting and uses PCB pin terminals for connections.
