Panasonic PCB Power Relay 9V DC Coil, 16A Switching Current, SPST ADW1109HLW

Panasonic ADW1109HLW PCB Power Relay is engineered for reliable power switching with a 9V DC coil and 16A switching current capability in an SPST contact configuration. Designed for mounting on PCBs with PCB pin terminals, this relay is part of the DW (ADW1) series known for its compact size and ability to handle high operating power safely.

The relay features silver alloy contacts delivering switching capacity of up to 277V AC, ensuring excellent conductivity and durability. The coil power is efficiently rated at 200mW, paired with a coil resistance of 405 ohms to optimize operation and power consumption.

Built to withstand demanding industrial and commercial conditions, the ADW1109HLW operates consistently between -40°C minimum and 70°C maximum temperatures, providing robust performance across diverse applications such as appliances, lighting controls, smart meters, power supplies, refrigerators, and washing machines. Its dimensions are specifically designed to fit compact PCB layouts, measuring 24mm length, 10mm width, and 15.8mm height.

Additional benefits include low contact resistance of 100 milliohms ensuring minimal electrical loss and high switching power rated at 4.4kVA. This relay series carries recognized certifications like UL, VDE, CSA, cUL, and cULus, confirming compliance to global safety standards.

The Panasonic ADW1109HLW relay is ideal for use in industrial automation, energy management, HVAC, commercial appliances, and lighting systems, where dependable switching and compact size are critical.

This relay is designed for PCB mount applications with PCB pin terminals. The compact ADW1 series relay maintains high reliability under stressful conditions. It operates efficiently with a coil power of 200mW and coil resistance of 405 ohms.

Suitable for AC switching voltage up to 277V AC with silver alloy contacts. Operating temperature range from -40°C to 70°C ensures robustness in varied environments. Dimensions measure 24mm in length, 10mm in width, and 15.8mm in height.

Contact resistance is low at 100 milliohms for optimal electrical performance. Applicable in appliances, industrial, energy, and lighting sectors. Meets standards and approvals including UL, VDE, CSA, cUL, and cULus certifications.

Explore more Panasonic Power Relays and electrical components at EnvMart for your industrial and commercial needs.
