Samtec TSM Series Vertical Surface Pin Header, 4 Contacts, 2.54 mm Pitch, 2 Rows, Unshrouded TSM-102-02-T-DV

Samtec TSM-102-02-T-DV is a vertical surface mount pin header designed for high-reliability board-to-board connections in modern electronic assemblies. This product features 4 phosphor bronze contacts arranged in 2 compact rows, offering efficient signal or power distribution across PCBs. The 2.54 mm pitch ensures compatibility with standard PCB layouts and allows seamless integration into a wide range of circuit designs.

The pin header utilizes a liquid crystal polymer housing, ensuring excellent mechanical strength and thermal stability. The contacts are gold-plated to maximize conductivity and resist corrosion, enabling consistent performance throughout the product’s lifetime. Its unshrouded structure provides easy access for inspection as well as simple engagement with mating connectors.

The TSM-102-02-T-DV offers a rated current of 5.4 A and supports up to 475 V voltage, making it suitable for both signal and moderate power applications in industrial, automation, instrumentation, and consumer electronics sectors. The component operates reliably from -55°C to 125°C, adapting well to varying environmental conditions.

Installation is streamlined with surface mount termination, supporting efficient automated PCB assembly and minimizing installation time. The connector’s male gender ensures compatibility with a variety of female headers or sockets used in PCB headers and wire housings.

Samtec’s TSM series is recognized for its robust build and secure connectivity. This model suits diverse PCB connector requirements such as signal transmission, sensor interfacing, power distribution, and module linking in embedded systems, manufacturing controls, industrial electronics, and laboratory setups.

Reliable vertical board-to-board connectivity for PCBs. Standard 2.54 mm pitch offers broad compatibility. Gold-plated contacts withstand repeated mating cycles. Liquid crystal polymer body ensures durability and thermal resistance.

Surface mount design is ideal for automated production lines. Wide operating temperature range from -55°C to 125°C. 4 contacts in 2 rows optimize space and connectivity. Rated for high-current and voltage applications. Unshrouded design facilitates easy access and inspection.

Industrial, laboratory, instrumentation, and automation applications supported. Explore additional products in the PCB Pin Header category on EnvMart to find matching connectors for your project requirements.
