Samtec TSW Series Straight Through Hole Pin Header, 26 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-113-14-G-D

The Samtec TSW-113-14-G-D is a straight through hole pin header engineered for demanding electronics and industrial applications. With 26 gold-plated phosphor bronze contacts arranged in two rows, it provides secure and reliable connectivity for board-to-board systems. The 2.54 mm pitch meets standard PCB requirements, making it compatible with a wide variety of layouts in embedded systems, industrial controls, and other electronic assemblies.

Its housing is made of glass filled polyester, offering enhanced mechanical stability, resistance to heat, and long-term electrical insulation. The gold plating on contacts ensures optimal current flow and protection against oxidation or corrosion. The through-hole mounting style allows for rigid mechanical attachment to the PCB, reducing the risk of loosened connections due to vibration or repeated insertions.

This unshrouded vertical header is preferred for ease of pin probing during development and for integration where space is limited. The male contact gender aligns with common board-to-board and wire-to-board interface requirements, and termination is via soldering, guaranteeing strong joints for both low and high-volume manufacturing.

The connector system supports operation across an industrial temperature range from -55°C to 125°C, with a rated voltage up to 550V. Applications include electronics manufacturing, laboratory systems, industrial automation, prototyping, and embedded hardware. Its compact dual-row configuration maximizes density without compromising on insertion strength.

By providing a wide choice of terminal lengths and options within the TSW series, Samtec pin headers like the TSW-113-14-G-D help PCB designers optimize layouts for signal, power, or mixed-use circuits.
