Wurth Elektronik 1210 Shielded Wirewound Surface Mount Inductor with Ferrite Core 15μH ±20% 8A Max DC Current 7447709150
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 8mm |
| Brand | Wurth Elektronik |
| Height | 10mm |
| Length | 12mm |
| Depth | 12mm |
| Packaging | Tape & Reel |
| Series | WE-PD |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 15μH |
| Standards/Approvals | REACH, RoHS |
| Package/Case | 1210 |
| Maximum DC Current | 8A |
| Pin Count | 2 |
| Maximum DC Resistance | 26mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 17MHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
| Recommended solder profile | Reflow |
Key Features
- The inductor features a ferrite core providing magnetic shielding.
- It is designed with a 1210 package suitable for surface mounting.
- Maximum DC resistance is low at 26mΩ ensuring efficiency.
- Operating temperature range is from -40°C to 125°C.
- The product complies with REACH and RoHS standards for environmental safety.
- Manufactured to automotive standard AEC-Q200 for high reliability.
- The component is supplied on tape and reel packaging optimized for automated assembly.
- Recommended solder profile is reflow compatible.
Product Description
Wurth Elektronik model 7447709150 is a 1210 size shielded wirewound surface mount inductor designed with a ferrite core. It offers an inductance value of 15μH with a tolerance of ±20% and supports a maximum DC current of 8A, making it suitable for high current applications in electronic circuits.
This SMD power inductor is magnetically shielded to reduce leakage fields and ensure minimal electromagnetic interference. It has a low DC resistance of 26mΩ and operates efficiently over a broad temperature range from -40°C to 125°C, complying with demanding automotive standard AEC-Q200.
This component features a tape and reel packaging format, allowing for efficient automated placement in manufacturing environments. It is molded for durability and designed for reflow soldering with a recommended solder profile to optimize assembly quality.
Applications include switching regulators with low operating voltages, integrated DC/DC converters, and graphics cards requiring high efficiency switching regulators with efficiencies greater than 86%. Its robust construction and magnetic shielding make it ideal for demanding industrial, electronic, automotive, and power supply applications.
The inductor is constructed with a ferrite core ensuring excellent magnetic performance. Its shielded design minimizes electromagnetic interference in compact PCB layouts. Supports continuous DC currents up to 8A for high load capability.
Can operate reliably in extreme temperature conditions between -40°C and 125°C. Compliance with REACH and RoHS regulations ensures environmental safety. Automotive standard AEC-Q200 certification assures quality and reliability for automotive electronics.
Package dimensions: length 12mm, height 10mm, depth 12mm, diameter 8mm. Recommended for surface mount technology with 2 pins for secure PCB attachment. Explore more electronic passive components and Surface Mount Inductors from leading brands like Wurth Elektronik at EnvMart to improve your designs with high-quality components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 15μH with a tolerance of ±20%.
It supports a maximum DC current of 8A, making it suitable for high load applications.
The package dimensions are 12mm in length, 10mm in height, and 12mm in depth, with a diameter of 8mm.
It operates reliably over a temperature range from -40°C to 125°C.
It is constructed with a ferrite core, which provides excellent magnetic performance and shielding.
The maximum DC resistance is 26mΩ, ensuring efficient operation.
It complies with REACH and RoHS standards for environmental safety, and meets the automotive standard AEC-Q200 for reliability.
It is supplied on tape and reel packaging, which is optimized for automated assembly processes.
The recommended solder profile is reflow compatible, suitable for surface mount technology.
The maximum self-resonant frequency is 17MHz, allowing for effective performance in high-frequency applications.
This model features 2 pins for secure attachment to the PCB.
It is suitable for applications such as switching regulators, integrated DC/DC converters, and graphics cards requiring high efficiency.
