Samtec TSW Series Straight Through Hole Pin Header 4 Contacts 2.54 mm Pitch 2 Rows Unshrouded TSW-102-17-L-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header 4 Contacts 2.54 mm Pitch 2 Rows Unshrouded TSW-102-17-L-D

Name: Samtec TSW Series Straight Through Hole Pin Header 4 Contacts 2.54 mm Pitch 2 Rows Unshrouded TSW-102-17-L-D
Brand: Samtec
SKU: 83890
Price: 0.65 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Model	TSW-102-17-L-D
Mount Type	Through Hole
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Standards/Approvals	RoHS Compliant
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Operating temp range	-55 °C to +125 °C with Gold -55 °C to +105 °C with Tin
Plating used	Au or Sn over 50 μ" (1.27 μm) Ni

Key Features

Provides a reliable board-to-board connection solution for electronic circuits.
Features 4 phosphor bronze contacts with gold plating for enhanced conductivity and durability.
Designed with a 2.54 mm pitch and 2 row configuration for easy integration with standard PCB layouts.
Through hole mounting ensures secure retention and robust mechanical stability.
Constructed with glass filled polyester housing rated for -55°C to 125°C operating temperatures.
Unshrouded straight orientation allows quick, direct soldering without obstructing insertion.
Rated for up to 550 V, suitable for a wide range of signal and power PCB applications.

Product Description

Samtec TSW-102-17-L-D is a high-quality straight through hole pin header designed for robust PCB board-to-board connections in industrial, instrumentation, and electronic assembly applications. Its 4-contact, dual row configuration and 2.54 mm pitch makes it compatible with standard PCB designs, allowing for simple, reliable integration.

The connector’s contacts are made from phosphor bronze, plated with gold, optimizing both electrical performance and corrosion resistance. The glass filled polyester housing ensures strength and high temperature tolerance, supporting continuous operation within an ambient range of -55°C to 125°C.

Through hole mounting provides secure mechanical fixation, ideal for environments subject to vibration or handling. The unshrouded, straight orientation streamlines soldering and inspection processes, facilitating efficient assembly and maintenance.

This pin header is rated up to 550 volts, making it suitable for signal transmission and low-power applications across a wide array of sectors, including manufacturing, laboratory electronics, automation, and commercial devices.

With RoHS compliance and terminal plating options (gold or tin over nickel), the product adheres to international safety and material standards, enabling usage in demanding electronics environments. Typical use cases include industrial controller boards, sensor interfacing, development kits, test fixtures, and embedded system prototypes.

Its compact footprint allows dense placement on PCBs, and the male contact gender ensures compatibility with standard female PCB sockets and wire housings. Each header supports solder termination, minimizing resistance at junctions and offering a durable connection.

Industries such as electronics manufacturing, R&D laboratories, and commercial assembly benefit from the TSW-102-17-L-D’s performance and reliability. For more options in PCB Pin Headers and electronic connectors, explore the Samtec range at EnvMart, or browse related categories in Electronics & Electricals.
