Winslow W30600 Series 2.54 mm Pitch Vertical 24 Way Through Hole Turned Pin Open Frame DIL Socket 5A W30624T3RC

The Winslow W30624T3RC is a high-quality vertical DIL socket featuring a 24-way configuration and a 2.54 mm pitch, engineered for reliable through-hole mounting in PCB assemblies. Designed as part of the Winslow W30600 series, it is optimized for robust IC integration and demanding industrial use.

This socket utilizes turned pins, manufactured with precise screw machining processes that yield half hard brass outer pins and beryllium copper alloy contacts, offering superior conductivity and contact stability. The contacts are gold plated with tin-plated outer pins, providing maximum corrosion resistance and consistent electrical performance in challenging environments.

The open frame housing, constructed from fibreglass reinforced polybutylene terephthalate (PBT) with a UL 94 V-0 fire retardant rating, facilitates excellent heat dissipation and minimizes mechanical stress during repeated insertions and removals. The straight knurled barrel design on the pins prevents rotation during the wire wrap process, ensuring secure and reliable connections.

Wire wrap termination is supported, making the W30624T3RC highly suitable for applications involving rapid prototyping, repair, or custom circuit modifications. With its vertical orientation and 15.24 mm row width, the socket accommodates high-density PCB layouts where space and signal integrity are critical.

This DIL socket is rated for a continuous current of 5A and a maximum operating temperature of 150°C, making it appropriate for use in industrial control systems, laboratory instrumentation, and commercial electronic equipment. The socket’s dimensions are: length 30.4 mm, width 17.66 mm, depth 3 mm, ensuring compatibility with standard DIP packages.

Winslow Adaptics W30600 series sockets are well-regarded for their precision engineering and durable construction, serving electronic designers, repair engineers, and manufacturers in sectors ranging from PCB assembly and electronic prototyping to industrial automation and reliable device interconnection.

Typical industrial and laboratory applications include automated test systems, industrial controls, electronic development boards, and replacement of DIP components in PCB layouts.
