Molex Automotive Connector Female Grey Cable, 80 Way, Crimp Termination 34566-0803
Specifications
| Country of Origin | China |
|---|---|
| Brand | Molex |
| Colour | Grey |
| Current | 11A |
| Height | 47.92mm |
| Depth | 100.8mm |
| IP Rating | IPx9K, IP67 |
| Width | 40.4mm |
| Gender | Female |
| Mount Type | Cable |
| Housing Material | Nylon |
| Contact Material | Copper Alloy |
| Series | 34566 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Sub Type | Receptacle Housing |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 4 |
| Pitch | 2.54 mm |
| Contact Plating | Gold, Silver, Tin |
| Number of Contacts | 80 |
Key Features
- Features a robust female receptacle housing suitable for automotive applications.
- Equipped with 80 crimp contacts for superior cable connectivity.
- Grey nylon housing with gold, silver, and tin plated copper alloy contacts for enhanced durability.
- Supports operational currents up to 11A and optimizes for cable mounting.
- Offers an IP rating of IPx9K and IP67 for high ingress protection against dust and water.
- Accommodates 4 rows of contacts and provides secure wire dress and keying options.
Product Description
The Molex 34566-0803 Automotive Connector is a high-performance cable mount connector designed for demanding automotive electronic systems. It is engineered to deliver reliable female crimp connections with an impressive 80-way contact configuration.
This connector features a grey nylon housing, ensuring mechanical strength and resistance to environmental stresses seen in automotive applications. Its gold, silver, and tin plated copper alloy contacts allow for consistent electrical conductivity and corrosion resistance in harsh conditions.
With crimp termination, the connector enables secure and efficient cable assembly and supports up to four rows of contacts, optimizing layout for complex wiring harnesses. The connector is rated for operational currents up to 11A, ensuring compatibility with high-power automotive electronics.
The Molex 34566-0803 is protected by IPx9K and IP67 ingress ratings, safeguarding the internal circuits from dust, high-pressure water jets, and temporary immersion. Its temperature tolerance from -40°C to +125°C assures performance in extreme climates, making it suitable for commercial vehicles, industrial machinery, and rugged transport systems.
Measuring 100.8mm in depth, 47.92mm in height, and 40.4mm in width, the compact form allows for flexible installation in tight spaces and supports wire dress and keying options for secure alignment during assembly. The connector complies with the MX123 series and provides 2.54mm pitch for precise cable organization.
Typical industrial applications include automotive harness assembly, commercial fleets, transport logistics, and industrial control systems where robust connectivity is essential. Browse more Molex connectors and related automotive interface products in EnvMart's Connectors & Electronics Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Molex Automotive Connector supports operational currents up to 11A, making it suitable for high-power automotive electronics.
This connector measures 100.8mm in depth, 47.92mm in height, and 40.4mm in width, allowing for flexible installation in tight spaces.
The connector has an IP rating of IPx9K and IP67, providing high ingress protection against dust and water.
It features a grey nylon housing and contacts made of gold, silver, and tin plated copper alloy for enhanced durability and conductivity.
The Molex 34566-0803 connector is equipped with 80 crimp contacts, allowing for superior cable connectivity.
This model operates effectively within a temperature range of -40°C to +125°C, suitable for extreme climates.
It utilizes crimp termination, enabling secure and efficient cable assembly for automotive applications.
The connector accommodates 4 rows of contacts, optimizing layout for complex wiring harnesses.
The contact pitch for this model is 2.54mm, allowing for precise cable organization.
Typical applications include automotive harness assembly, commercial fleets, transport logistics, and industrial control systems where robust connectivity is essential.
This connector is a female receptacle housing, designed for cable mounting in automotive applications.
The Molex Automotive Connector is manufactured in China, ensuring compliance with industrial standards.
