Norcomp Right Angle D-Sub Connector 15 Contacts, 2.77 mm Pitch, Through Hole, Steel, 4-40 Board Lock 178-015-513R571
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 1kV |
| Brand | Norcomp |
| Orientation | Right Angle |
| Current | 5A |
| Model | 178-015-513R571 |
| Mount Type | Through Hole |
| Housing Material | Steel |
| Contact Material | Brass |
| Series | 178 |
| Mounting Hardware | 4-40 Board Lock |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Shell | Steel, nickel plating |
| Pitch | 2.77mm |
| Insulator | Glass-filled thermoplastic, (260°C process temp) |
| Standards/Approvals | RoHS |
| Contact Plating | Gold Flash |
| Number of Contacts A | 15 |
| D-Sub Shell Size A | DA-15 |
| Contact Gender A | Female |
| D-Sub Shell Size B | DB-15 |
| Contact Gender B | Male |
| Stamped contacts | Brass | Plating: Gold flash |
Key Features
- Features a right-angle orientation for space-saving PCB layouts.
- Provides 15 contacts suitable for standard density DA-15 and DB-15 interfaces.
- Steel shell with nickel plating ensures improved shielding and durability.
- Mounts securely using 4-40 board lock hardware and through-hole technology.
- Operating voltage rated at 1 kV and current rating of 5A.
- Female contact interface with brass stamped contacts plated in gold flash.
- Designed with glass-filled thermoplastic insulator rated for high-temperature processing.
- Wide operating temperature range from -55°C to +105°C for demanding environments.
Product Description
The Norcomp 178-015-513R571 is a precision-engineered right angle D-sub connector designed for reliable signal connections in electronic, computing, and industrial control applications. With its robust steel shell, nickel plating, and 15 contact positions, this connector fits DA-15 and DB-15 standard densities and provides both mechanical stability and superior electrical performance.
This model offers a right-angle orientation, optimizing board space in densely packed PCB layouts. Using through-hole mounting and secure 4-40 board lock hardware, it ensures stable and vibration-resistant installation, making it ideal for critical and high-frequency environments.
The connector features female interface contacts made from stamped brass and plated with gold flash for optimal conductivity and corrosion resistance. It accommodates high-performance requirements, supporting up to 5A of current per contact and withstanding voltages up to 1 kV. The glass-filled thermoplastic insulator is engineered to tolerate process temperatures up to 260°C.
Designed for a wide temperature range, the 178-015-513R571 operates reliably from -55°C to 105°C, making it suited for applications in scientific instrumentation, industrial automation, laboratory electronics, and commercial computing equipment.
It adheres to RoHS standards, confirming environmental compliance and offering assurance of restricted hazardous substances. The connector is fully intermateable with other industry-standard D-sub connectors, supporting stacked configurations and providing enhanced grounding and retention with ground indents on the nickel-plated shell.
Typical use cases include industrial machinery controls, laboratory testing setups, computer interface expansion, and assembly in commercial electronics. Whether for manufacturing automation, scientific research, or HVAC system controls, this Norcomp connector delivers durable, high-performance connections.
Discover more D-Sub Connectors and Norcomp interface solutions by browsing the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Norcomp 178-015-513R571 has a current rating of 5A per contact.
This connector is rated for an operating voltage of 1 kV.
The housing is made of steel with nickel plating, while the contacts are brass with gold flash plating.
It operates reliably within a temperature range of -55°C to +105°C.
This model features 15 contacts suitable for DA-15 and DB-15 interfaces.
It uses through-hole mounting with 4-40 board lock hardware for secure installation.
The contact pitch for this model is 2.77 mm.
The insulator is made from glass-filled thermoplastic, rated for a processing temperature of 260°C.
Yes, the connector adheres to RoHS standards, confirming its compliance with environmental regulations.
This model features a right-angle orientation, which is designed for space-saving PCB layouts.
It has a female contact interface with brass stamped contacts plated in gold flash.
Typical applications include industrial machinery controls, laboratory testing setups, and computer interface expansion.
