Cosel DC/DC Converter 5V DC, 2A, 36V DC Input, 9V Min Input, 10W, PCB Mount, SIP-8, 85°C Max, MGFS102405
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGF DC/DC Converter, 5V dc/ 2 A, 36V dc Inpu |
| Brand | Cosel |
| Efficiency | 88% |
| Length | 22mm |
| Model | MGFS102405 |
| Depth | 12mm |
| Gross Weight | 7g |
| Width | 9.5mm |
| Mount Type | PCB |
| Series | MGF |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP-8 |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Ripple and Noise | 300mV Pk-Pk |
| Maximum Output Power | 10W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 9V |
| Number of Pins | 7 |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 2A |
| Output Voltage Adjustment Range | 4.90 to 5.21 V |
| Isolation Voltage | 1kV dc |
Key Features
- Provides stable 5V DC output for electronic and industrial systems.
- Wide input range from 9V to 36V DC supports diverse power sources.
- Compact SIP-8 package ensures space-efficient PCB mounting.
- Maximum output current of 2A and output power up to 10W.
- Includes overcurrent and overvoltage protection features for safety.
- Operating temperature range from -40°C to 85°C for high reliability.
- Minimal ripple and noise at 300mV Pk-Pk for sensitive circuitry.
- High efficiency up to 88% minimizes power loss.
Product Description
The Cosel MGFS102405 DC/DC Converter is a high-performance, compact power conversion module designed for demanding industrial, electronic, and laboratory applications. This converter provides a regulated 5V DC output at up to 2A, making it ideal for powering sensitive electronics, embedded devices, and control systems.
With its wide input voltage range from 9V to 36V DC, the MGFS102405 can accommodate various power sources and is suitable for environments where stable low-voltage operation is required. Its SIP-8 package and 7-pin configuration allow for straightforward PCB integration and space-constrained designs. The unit delivers a maximum output power of 10W, ensuring reliable operation even with higher current loads.
Designed for resilience, the converter operates from -40°C up to 85°C, offering dependable performance in harsh, high-temperature settings. Built-in protections against overcurrent and overvoltage enhance equipment safety and longevity. Minimal ripple and noise characteristics, measured at 300mV Pk-Pk, support use in sensitive analog and digital circuitry where clean power is crucial.
The MGFS102405 stands out for its efficiency, reaching up to 88%, which reduces heat generation and power consumption. Faraday-shielded construction and six-sided shielding boost electromagnetic compatibility, making it fit for industrial automation, laboratory instrumentation, communications, and embedded control systems. Isolation voltage of 1kV DC assures robust electrical isolation for critical system interfaces.
Applications include industrial controls, laboratory instrumentation, PLCs, measurement equipment, telecommunications, embedded systems, and commercial electronics requiring reliable DC/DC conversion. The module is RoHS compliant and conforms to CSA, cUL, CE, UKCA, UL62368-1, EN62368-1, and UL60950-1 standards for international regulatory requirements.
Explore further solutions in DC Converters and PCB-mount power supplies on EnvMart to find ideal options for your engineering, manufacturing, and laboratory power needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 9V to 36V DC.
The maximum output current of this unit is 2A.
It has an efficiency rating of up to 88%.
The maximum output power is 10W.
The dimensions of this model are 22mm in length, 12mm in depth, and 9.5mm in width.
The operating temperature range is from -40°C to 85°C.
This model is designed for PCB mounting.
The ripple and noise is specified at 300mV Pk-Pk.
The isolation voltage is 1kV DC.
It includes overcurrent and overvoltage protection features.
This unit is suitable for industrial controls, laboratory instrumentation, PLCs, and telecommunications, among others.
The output voltage is 5V DC.
