KEMET A72 Film Capacitor, 22 nF ±10 %, 1500 V dc, 450 V ac, Through Hole A72SQ2220AA00K

Free Delivery in India | Lowest Global Shipping Charges

KEMET A72 Film Capacitor, 22 nF ±10 %, 1500 V dc, 450 V ac, Through Hole A72SQ2220AA00K

Name: KEMET A72 Film Capacitor, 22 nF ±10 %, 1500 V dc, 450 V ac, Through Hole A72SQ2220AA00K
Brand: KEMET
SKU: 419982
Price: 9.61 USD
Availability: InStock



Category Film Capacitor Brand KEMET Condition New

Specifications

Country of Origin	Italy
Capacitance Range	47 pF - 0.33 μF
Diameter	5 - 22.5 mm
Brand	KEMET
Length	28mm
Model	A72SQ2220AA00K
Width	12.5mm
Mount Type	Through Hole
Series	A72
Maximum Operating Temperature	105°C
Tolerance	±10 %
Capacitance	22nF
Minimum Operating Temperature	-55°C
Terminal type	Axial
Dissipation Factor	0.1%
Lead Length	40mm
Standards/Approvals	IEC 60384-13, UL
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	450V ac
Rated DC Voltage	1500V dc
Lead Diameter	0.8mm
Capacitance tolerance	±5%, ±10%, ±20%

Key Features

Constructed with polypropylene film and metal foil or metallized film and metal foil for efficient performance.
Encapsulated in a plastic polyester tape wrapping case with thermosetting resin for durability.
Axial lead type with 0.8 mm lead diameter and 40 mm lead length for secure through hole mounting.
Operates reliably within temperature range from -55°C to 105°C.
Compliant with IEC 60384-13 and UL standards ensuring safety and performance.
Ideal for high frequency applications requiring stable capacitance.
Capacitance tolerance options include ±5%, ±10%, and ±20%.
Lead-free terminations and self-healing properties enhance operational reliability.

Product Description

The KEMET A72SQ2220AA00K is a high-quality Film Capacitor designed for electronic and industrial applications requiring stable capacitance and reliable voltage handling. Featuring a capacitance of 22 nF with ±10% tolerance, this capacitor supports a rated DC voltage of 1500 V and an AC voltage of 450 V, making it suitable for demanding high frequency circuits.

Constructed with polypropylene film and metal foil or metallized film and metal foil, the capacitor offers excellent electrical properties and long-term stability. The axial leads are electrically welded for secure connection and encapsulated within a plastic polyester tape wrapping case using thermosetting resin material, ensuring durability and insulation.

Operating temperature ranges from -55°C to 105°C, ideal for various industrial, laboratory, and electronic applications. It meets international standards including IEC 60384-13 and UL, guaranteeing compliance with safety and quality benchmarks.

The capacitor's physical dimensions include a length of 28 mm, width of 12.5 mm, and lead diameter of 0.8 mm with a 40 mm axial lead length, designed for secure through hole mounting onto PCBs. Its dissipation factor is low at 0.1%, enhancing performance in precise electronic circuits.

The product supports lead-free terminations and exhibits self-healing behavior, improving reliability and lifespan. Typical applications range from power electronics to high frequency circuits in automotive, industrial, and commercial environments.

Constructed from polypropylene film and metal foil or metallized film and metal foil. Plastic case encapsulation with thermosetting resin wrapping. Axial lead through hole mounting with 40 mm lead length. Operating temperature from -55°C up to 105°C.

Rated voltage: 1500 V DC, 450 V AC. Meets IEC 60384-13 and UL standards. Lead-free terminations with self-healing capability.

This KEMET film capacitor supports various electronics projects requiring stable, high voltage capacitors. It is perfect for industrial, laboratory, manufacturing, and electronic component integration tasks.
