TE Connectivity IP67 PCB Slide Switch SPDT Latching 400mA Polybutylene Terephthalate IP67
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Operating Temperature Range | -20 +80°C |
| Length | 9.5mm |
| Model | IP67 |
| Depth | 10.8mm |
| IP Rating | IP67 |
| Width | 5mm |
| Mount Type | PCB |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPDT |
| Contact Rating | 4VA @ 20Vdc max |
| Switch Configuration | On-None-On |
| Minimum Operating Temperature | -20°C |
| Terminal type | Solder |
| Standards/Approvals | RoHS, UL |
| Switch Operation | Latching |
| Contact DC Voltage | 48V dc |
| Switch Contact Current | 400mA |
| Mechanical Life | 30000Operations |
| Contact AC Voltage | 48V ac |
| Electrical Life | 10000 operations |
| Actuator Material | Polybutylene Terephthalate |
Key Features
- Features a single-pole double-throw (SPDT) contact configuration.
- Through-hole PCB mount for easy installation and solder terminals.
- Latching switch operation ensures reliable on/off control.
- Supports a maximum switch contact current of 400mA and voltage ratings up to 48V AC/DC.
- IP67 rated for water and dust resistance, suitable for harsh industrial conditions.
- Actuator is made of durable polybutylene terephthalate for long service life.
- Mechanical life expectancy of 30,000 operations and electrical life of 10,000 operations.
- Operating temperature range from -20°C to 80°C.
Product Description
TE Connectivity IP67 PCB Slide Switch model IP67 is a robust, latching slide switch designed for PCB mounting. It features a SPDT contact configuration with a switch contact current rating of 400mA, supporting both AC and DC voltages up to 48V. The actuator material is polybutylene terephthalate, providing durability and reliability in operation.
This compact switch measures 9.5mm in length, 5mm in width, and 10.8mm in depth, making it suitable for applications where space is limited. It offers a high mechanical life of 30,000 operations and electrical life rating of 10,000 operations, ensuring long-term usability in industrial settings.
The IP67 rating certifies that the switch is dust-tight and protected against temporary immersion in water, making it ideal for harsh environmental conditions including industrial, laboratory, and marine applications.
The slide switch operates within a temperature range of -20°C to 80°C, supporting reliable functioning across diverse climates. It uses solder terminal types and features a break-before-make configuration for safe switching.
Typical use cases include test equipment, aqua marine pumps, and other automation and control systems where reliable switch operation and protection against ingress are critical. Single-pole double-throw (SPDT) contact configuration.
Through-hole PCB mounting with solder terminals. Latching switch operation mode. Switch contact current: 400mA with 48V AC/DC voltage rating. IP67 ingress protection rating. Actuator made from polybutylene terephthalate.
Dimensions: 9.5mm (L) × 5mm (W) × 10.8mm (D). Mechanical life of 30,000 operations; electrical life of 10,000 operations. Operating temperature range: -20°C to 80°C. Contact rating of 4VA at 20Vdc max.
Choose TE Connectivity IP67 Slide Switch for reliable, compact, and sealed switching solutions in industrial and electronic applications. Explore more in our Electronics & Electricals category for quality control components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a single-pole double-throw (SPDT) contact configuration, allowing for versatile switching options.
The maximum switch contact current for this unit is 400mA, making it suitable for various applications requiring this level of current.
It supports voltage ratings up to 48V AC and 48V DC, providing flexibility for different electrical systems.
This switch has an IP67 rating, which means it is dust-tight and protected against temporary immersion in water, suitable for harsh environments.
The operating temperature range for this slide switch is from -20°C to 80°C, allowing it to function reliably in diverse climates.
It uses through-hole PCB mounting with solder terminals, facilitating easy installation on printed circuit boards.
The mechanical life expectancy of this switch is rated at 30,000 operations, ensuring long-term usability.
The actuator of this model is made from polybutylene terephthalate, which contributes to its durability and reliability in operation.
The electrical life of this switch is rated at 10,000 operations, indicating its longevity in electrical applications.
This unit measures 9.5mm in length, 5mm in width, and 10.8mm in depth, making it compact for various applications.
This switch is compliant with RoHS and UL standards, ensuring it meets specific safety and environmental criteria.
Typical applications include test equipment, aqua marine pumps, and automation and control systems where reliable switch operation is critical.
