Bourns 5020 Shielded Wirewound Surface Mount Inductor Ferrite Core 12 μH Semi Shielded ±20 % 1.4 A SRN5020TA
Specifications
| Country of Origin | China |
|---|---|
| Brand | Bourns |
| Height | 1.8mm |
| Length | 5mm |
| Model | SRN5020TA |
| Depth | 5mm |
| Packaging | Tape & Reel |
| Series | SRN5020TA |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance Range | 0.6to100 μH |
| Inductance | 12μH |
| Standards/Approvals | RoHS |
| Package/Case | 5020 |
| Maximum DC Current | 1.4A |
| Maximum DC Resistance | 135mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 36MHz |
| Minimum Quality Factor | 15 |
| Inductor Construction | Semi Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a ferrite core for enhanced magnetic properties.
- Inductance tolerance is ±20%, ensuring precision performance.
- Supports a maximum DC current of 1.4 A.
- Surface mount package 5020 suitable for compact PCB designs.
- Meets automotive standard AEC-Q200 for reliability in harsh environments.
- Operating temperature range from -55°C to 125°C.
- Maximum DC resistance of 135 mΩ minimizes power loss.
- Inductor construction is semi shielded to reduce electromagnetic interference.
Product Description
Bourns SRN5020TA is a 5020 shielded wirewound surface mount inductor with a ferrite core, providing 12 μH inductance with a ±20% tolerance. Designed for compact and efficient power management circuits, this semi-shielded inductor supports currents up to 1.4 A and a high maximum self-resonant frequency of 36 MHz.
The device features a robust ferrite core construction enclosed within a semi-shielded design to ensure minimized electromagnetic interference (EMI), highly suitable for automotive and industrial applications adhering to the AEC-Q200 standard. The physical package measures 5 mm length, 1.8 mm height, and 5 mm depth, enabling integration into dense surface mount assemblies with tape & reel packaging for automated assembly processes.
This surface mount inductor operates reliably across a wide temperature range of -55°C to 125°C with a low maximum DC resistance of 135 mΩ, offering efficient energy transfer with minimal losses. It is RoHS compliant, supporting green manufacturing processes.
Typical applications include DC/DC converters, power supplies, and filters requiring stable inductance and high current capacity. Its semi-shielded wirewound construction ensures excellent quality factor and performance stability in demanding electronic environments.
Features a ferrite core for enhanced magnetic properties. Inductance tolerance is ±20%, ensuring precision performance. Supports a maximum DC current of 1.4 A. Surface mount package 5020 suitable for compact PCB designs.
Meets automotive standard AEC-Q200 for reliability in harsh environments. Operating temperature range from -55°C to 125°C. Maximum DC resistance of 135 mΩ minimizes power loss. Inductor construction is semi shielded to reduce electromagnetic interference.
RoHS compliant ensuring environmental safety. Suitable for use in DC/DC converters and power supplies. Explore the Bourns range of Surface Mount Inductors on EnvMart for reliable and high-performance electronic components tailored to your industrial and automotive needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRN5020TA has an inductance value of 12 μH with a tolerance of ±20%.
This model supports a maximum DC current of 1.4 A.
It operates reliably within a temperature range of -55°C to 125°C.
The maximum DC resistance of the SRN5020TA is 135 mΩ, which helps minimize power loss.
This inductor has a maximum self-resonant frequency of 36 MHz.
The dimensions of this unit are 5 mm in length, 1.8 mm in height, and 5 mm in depth.
It features a semi-shielded construction to reduce electromagnetic interference (EMI).
Yes, it meets the automotive standard AEC-Q200 and is RoHS compliant.
This inductor is packaged in tape & reel format, suitable for automated assembly processes.
Typical applications include DC/DC converters, power supplies, and filters requiring stable inductance.
The core material of this inductor is ferrite, which enhances its magnetic properties.
The minimum quality factor for this model is 15, indicating its performance stability.
