Isocom DC Input Optocoupler Through Hole 2-Pin DIP TLP621GR

The Isocom TLP621GR DC Input Optocoupler is designed to provide reliable optical isolation in electronic circuits. Packaged in a 2-pin DIP through-hole casing, it integrates an infrared LED coupled with an NPN silicon phototransistor that effectively isolates inputs to outputs and protects sensitive circuitry from high voltages and noise.

This component supports a maximum forward voltage of 1.3V, ensuring low power consumption on the input side, and operates with typical rise and fall times of 2μs and 3μs respectively, enabling high-speed switching applications.

Operating comfortably within a temperature range of -30°C to +100°C, the TLP621GR is suitable for diverse industrial and commercial environments. The input current handling capability is up to 50mA, combined with a current transfer ratio of 100% to 300%, supporting effective signal amplification and isolation.

The unit is UL certified and comes packaged in tubes for ease of use and inventory management. This optocoupler series applies broadly in computer terminals, industrial system controllers, measuring instruments, and transmit signals across different potential circuits, ensuring system integrity and safety.

Through-hole mount type for ease of PCB installation. High isolation voltage rating of 5300Vrms for robust electrical separation. Efficient performance with low forward voltage and high current transfer ratios. Fast switching speeds suitable for timing-sensitive applications.

Wide operating temperature range for reliability under varied conditions.

For electronics and electrical components in industrial, manufacturing, and instrumentation applications, the Isocom TLP621GR offers a balance of performance, durability, and compliance. Explore the extensive range of Optocouplers and related components available on EnvMart for your design and repair needs.
