Vishay 14 PPR Pulse Absolute Mechanical Rotary Encoder with 12.7 mm Round Shaft, Panel Mount RAME012M11114JB
Specifications
| Country of Origin | France |
|---|---|
| Brand | Vishay |
| Model | RAME012M11114JB |
| Mount Type | Panel |
| Current Rating | 100mA |
| Series | RAME012 |
| Shaft Diameter | 12.7mm |
| Shaft Length | 18.6mm |
| Pulses per Revolution | 14ppr |
| Standards/Approvals | RoHS |
| Termination Style | Wire |
| Shaft Style | Round |
| Encoder Reading | Absolute |
| Encoder Signal | Binary |
Key Features
- The encoder provides an absolute reading with a binary signal output.
- It features a shaft length of 18.6 mm and is designed for panel mount applications.
- Termination style is via wire for easy connection.
- Meets RoHS compliance standards, ensuring environmental safety.
- Rated for a current of 100 mA, suitable for various industrial uses.
- Constructed with high precision for harsh condition environments.
- Utilizes Hall effect principle ensuring immunity to external magnetic interference.
- Operating temperature range from -40 °C to +105 °C for reliable performance.
Product Description
Vishay RAME012M11114JB is a high-precision 14 pulse per revolution absolute mechanical rotary encoder featuring a 12.7 mm round shaft and panel mount design. It is engineered for industrial and electronic sensor applications requiring absolute position feedback with binary signal output. This encoder is constructed to operate reliably in harsh conditions and offers immunity to external magnetic fields due to its Hall effect sensor principle.
The product features a shaft length of 18.6 mm and wire termination style, facilitating straightforward installation and integration into control panels. Designed with environmental compliance, it carries RoHS certification ensuring it meets strict hazardous substance standards.
Ideal for industrial machinery, automation systems, and electronic component assemblies, the encoder supports a current rating of 100 mA and operates in a wide temperature range from -40 °C to +105 °C. Its durable construction and precise position sensing enhance control accuracy and operational reliability.
This encoder is manufactured in France under the RAME012 series, underscoring its premium quality and engineering standard. Suitable for use in construction, manufacturing, HVAC controls, and laboratory instrumentation, it complements a broad range of sensing and control applications.
The encoder provides an absolute reading with a binary output signal. Incorporates a high precision Hall effect sensor for reliable position detection. Panel mount installation with a robust 12.7 mm round shaft. Wire termination enables secure and flexible wiring.
Operating temperature range of -40 °C to +105 °C suitable for harsh environments. Meets RoHS standards for environmental safety compliance. Supports a current rating of 100 mA suitable for diverse industrial applications.
High pulse resolution of 14 pulses per revolution for precise feedback. Manufactured in France ensuring quality and reliability. Explore a wide array of Mechanical Rotary Encoders for industrial sensors and automation at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a high pulse resolution of 14 pulses per revolution (ppr), enabling precise position feedback.
The encoder operates reliably within a temperature range of -40 °C to +105 °C, making it suitable for harsh environments.
It outputs an absolute reading with a binary signal, suitable for various industrial applications.
The encoder features a round shaft with a diameter of 12.7 mm and a length of 18.6 mm.
The encoder has a current rating of 100 mA, which is suitable for diverse industrial uses.
It utilizes a wire termination style, facilitating straightforward installation and integration into control panels.
Yes, this model meets RoHS compliance standards, ensuring it adheres to strict hazardous substance regulations.
This encoder is designed for panel mount applications, providing a secure installation option.
The encoder is manufactured in France, underscoring its quality and engineering standards.
It is ideal for use in industrial machinery, automation systems, and electronic component assemblies.
This model is part of the RAME012 series, which includes various mechanical rotary encoders.
It incorporates a high precision Hall effect sensor, ensuring immunity to external magnetic interference for reliable position detection.
