MEAN WELL RSD-30 DC/DC Converter 24V DC Output, 36V DC Maximum Input, 1.25A Output Current, Chassis Mount RSD-30G-24
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters MEAN WELL RSD-30 DC/DC Converter, 24V dc/, 36V dc |
| Brand | MEAN WELL |
| Efficiency | 89% |
| Length | 113mm |
| Model | RSD-30G-24 |
| Depth | 25mm |
| Gross Weight | 250g |
| Width | 60mm |
| Mount Type | Chassis Mount |
| Series | RSD-30 |
| Minimum Operating Temperature | 70°C |
| MTBF | 396900h |
| Number of outputs | 1 |
| Ripple and Noise | 50mV Pk-Pk |
| Maximum Output Power | 30W |
| Maximum Input Voltage | 36V dc |
| Standards/Approvals | CE |
| Minimum Input Voltage | 9V |
| Output Voltage 1 | 24V dc |
| Output Current 1 | 1.25A |
| Isolation Voltage | 4kV dc |
| Input Ratio | 1:6 |
| Input Ratio1 | 6 |
Key Features
- Compact 1U low profile with 25mm depth for space-saving installation.
- Wide input voltage range from 9V to 36V DC ensuring operational flexibility.
- High efficiency of 89% minimizes power loss during conversion.
- Built-in isolation voltage of 4000V DC for reliable electrical separation.
- Low ripple and noise at 50mV peak-to-peak for stable output.
- Compliance with CE standards and up to 70°C operating temperature.
- Provides single output with constant current limiting protection.
- Robust MTBF rating of 396,900 hours ensures long-term reliability.
Product Description
MEAN WELL RSD-30G-24 DC/DC Converter is a highly reliable and compact power supply device designed to convert voltages efficiently in industrial and electronic applications. It features a 24V DC output voltage with a maximum input voltage of 36V DC, supporting an output current of 1.25A. Its chassis mount form factor enables easy and secure installation in control cabinets and power distribution setups.
The device operates efficiently with an 89% efficiency rating, reducing energy waste and thermal load. It includes an isolation voltage of 4000V DC that provides electrical isolation between input and output, essential for safety in sensitive electronics environments. Ripple and noise levels are minimized to 50mV peak-to-peak, ensuring a stable and clean output power supply.
With a wide input voltage range from 9V to 36V DC and a 1U low profile design of 25mm depth, this converter suits space-restricted applications. It is built to operate within a temperature range up to 70°C, meeting demanding environmental conditions. An MTBF of nearly 400,000 hours underscores the product's durability and long lifecycle.
This model complies with CE standards and incorporates safety features including constant current limiting and LED indicator for power status. The half encapsulated construction allows effective cooling via free air convection. Suitable for industrial, electronic, and automation use cases, the RSD-30 series is known for reliability in power conversion.
Package includes one MEAN WELL RSD-30G-24 DC/DC Converter unit designed for immediate deployment in relevant systems. MEAN WELL provides a 3-year warranty on all RSD series devices, assuring quality and customer support.
Explore more DC/DC Converters and power supply solutions in the MEAN WELL product range available at EnvMart, your reliable industrial component partner. Compact 1U profile with 25mm depth for space efficiency. Wide input voltage range of 9V to 36V DC.
High output efficiency of 89% reducing power loss. 4000V DC isolation voltage for enhanced safety. 50mV peak-to-peak ripple and noise ensuring stable output. Operation up to 70 °C ambient temperature. Single output with 1.25A current capacity.
Chassis mount for solid installation. Robust MTBF of 396,900 hours ensures dependable performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The output voltage of this model is 24V DC.
The maximum input voltage for this converter is 36V DC.
It has an efficiency rating of 89%, which minimizes power loss during conversion.
The maximum output current of the RSD-30G-24 is 1.25A.
The dimensions of this unit are 113mm in length, 60mm in width, and 25mm in depth.
The isolation voltage is 4000V DC, providing reliable electrical separation between input and output.
This model operates within a temperature range up to 70°C.
The ripple and noise level is minimized to 50mV peak-to-peak, ensuring stable output.
This converter features a chassis mount design for secure installation.
The MTBF (Mean Time Between Failures) rating is approximately 396,900 hours.
This model complies with CE standards, ensuring it meets certain safety and performance criteria.
The minimum input voltage for this converter is 9V DC.
