TE Connectivity PCB Power Relay 24V ac Coil 8A Switching Current DPDT XT424R24 1887203-3
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Height | 26.7mm |
| Length | 29mm |
| Model | XT424R24 1887203-3 |
| Width | 13.7mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | XT |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 8A |
| Terminal type | Through Hole |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 350Ω |
| Coil Voltage | 24V ac |
| Switching AC Voltage | 400V ac |
| Coil Power | 760mW |
Key Features
- Designed for PCB mounting with through-hole terminals for secure installation.
- Operates efficiently with a coil resistance of 350Ω and coil power of 760mW.
- Built to switch AC voltage up to 400V with silver alloy contacts ensuring durability.
- Suitable for operation in temperatures from -40°C to 70°C, ensuring wide environmental compatibility.
- Compact dimensions measuring 29mm length, 26.7mm height, and 13.7mm width.
- Features low contact resistance of 100mΩ for minimal power loss.
- Conforms to RoHS standards reflecting environmentally responsible manufacturing.
- Ideal for panel boards, mechanical engineering, and industrial control applications.
Product Description
TE Connectivity XT424R24 1887203-3 PCB Power Relay is engineered with a 24V AC coil and DPDT (Double Pole Double Throw) contact configuration, supporting switching currents up to 8A. This power relay is specifically designed for printed circuit board (PCB) mounting, featuring through-hole terminal types that provide secure and stable connections in industrial environments.
The relay’s coil resistance is rated at 350Ω, drawing a coil power of 760mW, facilitating efficient energy consumption. Silver alloy contacts ensure durability and reliable conductivity, capable of managing switching AC voltages up to 400V. It has a low contact resistance of 100mΩ which reduces energy losses during operation.
Designed to perform under a wide temperature range from -40°C to 70°C, this relay is suitable for various industrial and commercial applications, including panel boards and mechanical engineering systems. It features reinforced insulation and protection class II compliance according to VDE 0700 standards, ensuring operational safety and reliability.
With compact dimensions of 29mm in length, 26.7mm in height, and 13.7mm in width, it fits efficiently into dense PCB layouts. This relay is RoHS compliant, aligning with environmental and health safety standards. Manufactured in China, it is ideal for use in HVAC, automation, manufacturing, and control equipment industries where dependable power relay solutions are required.
Designed for PCB mounting with through-hole terminals for secure installation. Operates efficiently with a coil resistance of 350Ω and coil power of 760mW. Built to switch AC voltage up to 400V with silver alloy contacts ensuring durability.
Suitable for operation in temperatures from -40°C to 70°C, ensuring wide environmental compatibility. Compact dimensions measuring 29mm length, 26.7mm height, and 13.7mm width. Features low contact resistance of 100mΩ for minimal power loss.
Conforms to RoHS standards reflecting environmentally responsible manufacturing. Ideal for panel boards, mechanical engineering, and industrial control applications. Manufactured in China with reinforced insulation and protection class II (VDE 0700) compliance.
Explore the extensive range of Power Relays at EnvMart to find products that meet your industrial control and automation requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage rating for this model is 24V AC.
This relay can handle a maximum switching current of 8A.
The dimensions of this unit are 29mm in length, 26.7mm in height, and 13.7mm in width.
It supports PCB mounting with through-hole terminals for secure installation.
The contact configuration is DPDT (Double Pole Double Throw).
It operates efficiently in temperatures ranging from -40°C to 70°C.
The coil resistance is rated at 350Ω.
This relay can switch AC voltages up to 400V.
The contacts are made of silver alloy, ensuring durability and reliable conductivity.
The contact resistance is low at 100mΩ, which minimizes power loss during operation.
Yes, this relay conforms to RoHS standards, reflecting environmentally responsible manufacturing practices.
It is ideal for applications in panel boards, mechanical engineering, and industrial control systems.
