Omron G3VM Series Solid State Relay Surface Mount 20V Load 200mA Maximum Load Current

Omron G3VM-26M10 Solid State Relay is a high-performance MOSFET relay designed for reliable switching in various electronic and electrical applications. It supports a maximum load current of 200 mA and can handle load voltages up to 20 V, ideal for controlling low voltage circuits with good efficiency.

This solid state relay features a surface mount package with compact dimensions (10 mm length, 5 mm width, and 11 mm height), facilitating easy PCB terminal mounting in automated assembly lines. Its single pole double throw (SPDT) contact configuration and AC/DC switching capabilities make it suitable for a wide range of industrial, laboratory, and manufacturing uses.

Operating effectively between -30°C and 80°C ambient temperatures, this relay ensures consistent performance even in varied environmental conditions. It has a minimal off state leakage current of 1 μA and a capacitance of 1 pF, which contribute to reducing power loss and maintaining signal integrity.

Compliant with RoHS and UL certifications, the Omron G3VM-26M10 solid state relay meets stringent safety and quality standards. Manufactured in Japan, it guarantees superior build quality and durability for demanding electrical control tasks.

Applications of this relay include use in automation, electrical control panels, signal conditioning circuits, and sensitive electronic equipment requiring silent, rapid switching with no mechanical wear.

Offers high reliability with MOSFET output type. SPDT contact configuration ensures versatile switching. Operates within -30°C to 80°C temperature range for robust performance. Compact package dimensions of 10mm length, 5mm width, and 11mm height.

Surface mount type suitable for PCB terminal integration. Low off state leakage current of 1 μA to minimize power loss. Capacitance of 1 pF provides excellent signal integrity. Supports AC and DC switching functions for broad application use.

Complies with RoHS and UL safety standards. Manufactured in Japan ensuring high quality standards. Explore more Solid State Relays and related automation components on EnvMart for industrial and commercial applications.
