TRACOPOWER High Performance 100W Isolated DC/DC Converter 36V Input 9-36V, 9.6V Output, 8.4A, 90% TEQ 100-2412WIR

TRACOPOWER TEQ 100-2412WIR is a high-performance, isolated 100W DC/DC converter designed for industrial and railway applications. It supports an ultra-wide 4:1 input voltage range from 9V to 36V and delivers a stable output voltage of 9.6V at 8.4A current. The device achieves up to 90% efficiency and operates reliably in temperatures ranging from -40°C to 95°C with appropriate power derating.

The rugged metal case provides excellent thermal convection and enhanced vibration and shock resistance, making it suitable for harsh industrial environments. The converter features output voltage adjustment range from -20% to +10%, remote ON/OFF control, under voltage lockout, and input protection filters, ensuring secure and flexible operation.

With five isolated outputs and an isolation voltage of 2250 VDC, the TEQ 100-2412WIR guarantees safety and adaptability in complex electrical systems. It is particularly suited for chassis mounting in industrial equipment where PCB mounting is not feasible. The device complies with industry standards such as UL 60950-1, IEC/EN 60950-1, UL 508, and EN50155, supporting railway and battery-operated applications.

The package enables efficient use in manufacturing, power systems, railway automation, and other commercial or industrial environments requiring stable DC power conversion. With a length of 88.9mm and depth of 103.2mm, it offers a compact footprint for versatile installation.

Specifications such as MTBF of 711,000 hours underline its reliability in continuous operation. This converter is an industrial-grade solution for demanding applications that require rugged, efficient, and reliable DC power conversion.

High power block with 100W output and 90% efficiency. Wide input voltage range of 9V to 36V supports various industrial applications. Operates between -40°C and 95°C with power derating for harsh environments. Rugged sealed metal casing provides excellent thermal convection and vibration resistance.

Features 5 isolated outputs with output voltage trimming and remote ON/OFF control. Input protection filter and soft start circuit enhance reliability and performance. Isolation voltage rated at 2250 VDC ensures safety in industrial setups.

Designed for chassis mounting where PCB mounting is not feasible. MTBF rated at 711,000 hours indicating high durability and reliability. Explore EnvMart's comprehensive range of DC/DC Converters and industrial power supplies for robust and efficient electrical power management solutions.
