STMicroelectronics Operational Amplifier Dual Channel 3.5 MHz Gain Bandwidth 16 V SOIC 8-Pin TS272IDT

STMicroelectronics TS272IDT operational amplifier offers a dual-channel configuration with a gain bandwidth product of 3.5 MHz. It is housed in an 8-pin SOIC package compatible with surface mount technology, making it suitable for compact electronic designs. This device operates with supply voltages from 5 V up to 16 V, allowing flexibility in design applications across various industrial and commercial environments.

The TS272IDT provides excellent performance with a low input bias current of 300 pA and typical input offset voltage of 3 mV, enhancing precision in analog signal processing. Its slew rate of 5.5 V/μs supports fast signal transitions and better response in dynamic applications. The output voltage can swing to ground, maximizing the output signal range for more effective control and amplification.

Built to endure harsh environments, this operational amplifier functions reliably over a temperature range of -40°C to 125°C, suitable for automotive, industrial, and laboratory applications. The output current capability of 45 mA supports driving various loads directly. The device's RoHS compliance assures environmentally responsible manufacturing and disposal.

Compact dimensions of 5 mm length, 4 mm width, and 1.65 mm height enable convenient integration into printed circuit boards with limited space. The dual channel design supports circuits requiring two operational amplifiers in a single package, improving efficiency and design compactness.

Excellent consumption-to-speed ratio for power-efficient operation. Dual channel with 8-pin SOIC package for compact electronic designs. Wide voltage supply range from 5 V to 16 V for versatile applications. Low input bias current of 300 pA enhances measurement accuracy.

Slew rate of 5.5 V/μs supports rapid signal changes. Input offset voltage typically 3 mV for precise signal conditioning. Output current up to 45 mA capable of driving diverse loads. Operating temperature range from -40°C to 125°C ensures reliability.

Package dimensions optimized for surface-mount technology usage. RoHS compliant for environmentally conscious applications.

Ideal for use in industrial, automotive, laboratory instrumentation, electronic design, and power management systems. The TS272IDT supports a broad range of signal amplification and analog control needs in sophisticated applications.
