Texas Instruments Bus Switch 8 x 1:1 Logic IC 20-Pin TSSOP SN74CB3T3245PW
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 6.5mm |
| Model | SN74CB3T3245PW |
| Mount Type | Surface |
| Compatibility | Input TTL, Output TTL |
| Series | SN74CB3T3245 |
| Configuration | 8 x 1:1 |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 20 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | CB3T |
| Minimum Supply Voltage | 2.3V |
| Maximum High Level Output Current | -128mA |
| Maximum Low Level Output Current | 128mA |
| Maximum On State Resistance | 5Ω |
| Bus Width | 8bit |
| Configuration8 x 1 | 1 |
| Texas Instruments, Bus Switch, 8 x 1 | 1, 20-Pin TSSOP |
Key Features
- Operates within a supply voltage range of 2.3 to 3.6 volts.
- Features a maximum on state resistance of 5 ohms for efficient signal passing.
- Designed for surface mounting on PCBs with compact 20-pin TSSOP package.
- Supports a bus width of 8 bits with 1 element per chip configuration.
- Operating temperature range from -40°C to 85°C for industrial reliability.
- Compatible for Input TTL and Output TTL signal levels.
- Maximum high-level output current of -128 milliamps and low-level output current of 128 milliamps.
- Compact dimensions with a height of 1.15 mm and length of 6.5 mm.
Product Description
Texas Instruments SN74CB3T3245PW is a high-performance bus switch logic IC designed for signal switching and bus interfacing applications in electronic circuits. This model features an 8 x 1:1 configuration implemented in a 20-pin TSSOP package suited for surface mount technology. Operating voltage ranges from 2.3V to 3.6V, which makes it compatible with a range of low-power digital logic systems.
The device achieves a maximum on state resistance of 5 ohms, providing low resistance path for signals, thus maintaining signal integrity during switching operations. The SN74CB3T3245PW supports an 8-bit bus width with a single element per chip, facilitating efficient digital signal routing.
Designed to operate reliably within an ambient temperature range of -40°C to 85°C, it is suitable for industrial and commercial applications requiring robust performance. The component is designed for Input TTL and Output TTL compatibility ensuring seamless interfacing with TTL logic devices.
Its compact 20-pin TSSOP footprint with dimensions 6.5 mm length and 1.15 mm height allows space-saving PCB designs. The maximum output current ratings are -128mA for high level and 128mA for low level, supporting typical digital load requirements.
This bus switch IC finds applications in digital signal routing, reconfiguration, and system-level bus control across industrial electronics, instrumentation, and embedded systems. Suitable usage scenarios include signal multiplexing, bus isolation, and data bus management in electronic manufacturing and assembly.
Operates over a 2.3 to 3.6 V supply voltage range. Compact 20-pin TSSOP surface mount package. Bus width configuration of 8 bits with 1 element per chip. High reliability with a wide temperature range from -40°C to 85°C.
Signal compatible with TTL input and output standards. Low on state resistance at 5 ohms ensures low power loss. Dimensions of 6.5 mm length and 1.15 mm height optimize PCB layout. Explore a wide range of semiconductor components including Bus Switches at EnvMart for reliable industrial and commercial electronics solutions.
