TE Connectivity 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 10 μH ±10% 250 mA Idc Q:50 3613C100K

TE Connectivity 3613C100K is a high-quality shielded wirewound surface mount inductor housed in a compact 1812 package size. Featuring a ferrite core, it provides stable inductance of 10 μH with an inductance tolerance of ±10%. This inductor supports a maximum DC current of 250 mA and operates effectively within a temperature range from -30°C to 100°C, making it suitable for various industrial and commercial electronic applications.

The construction is wirewound and moulded with solder termination style, ensuring robust mechanical and electrical performance. The shielding improves electromagnetic interference immunity to maintain signal integrity in tightly packed electronic circuits. Its maximum DC resistance is 1.6Ω, balancing efficiency and performance, while the minimum quality factor of 50 enables efficient tuning characteristics in RF and power supply circuits.

The maximum self-resonant frequency of 20 MHz broadens application scope to high-frequency domains. This component is housed in tape packaging, optimized for automated assembly and surface mount technology production lines. It complies with RoHS standards, endorsing environmentally safe manufacturing processes.

Typically used in power supplies, telecommunications, automotive electronics, and consumer electronics, the 3613C100K is a versatile choice for designers demanding reliable passive components. Its compact dimensions (4.5mm length, 3.2mm height, and 3.2mm depth) allow dense circuit board layouts without compromising performance.

Compact 1812 package size measuring 4.5mm x 3.2mm x 3.2mm. Maximum DC resistance of 1.6Ω ensures efficient operation. Shielded design reduces electromagnetic interference. Ferrite core and wirewound construction provide stability and high quality factor.

Operating temperature range from -30°C to 100°C. Termination style is solder for reliable surface mount assembly. Maximum self-resonant frequency up to 20 MHz suitable for high-frequency applications. RoHS compliant ensuring environmental safety.

Tape packaging designed for automatic mounting processes. Manufactured in Taiwan, Province Of China. Explore more TE Connectivity inductors and passive components at EnvMart to ensure optimal performance for your electronic design and manufacturing needs.
