Bourns Shielded Wirewound Surface Mount Inductor, 33 μH ±20 %, 3.15 A IDC, Ferrite Core, 1060 Package SRN1060

Bourns SRN1060 shielded wirewound surface mount inductor offers a 33 μH inductance with ±20 % tolerance, designed with a ferrite core and semi magnetic shielding to minimize electromagnetic interference. The device supports a maximum DC current of 3.15 A and features a compact 1060 package size measuring 9.8 mm in length, 6 mm in height, and 10 mm in depth, making it suitable for various compact electronic designs.

This inductor is constructed using wirewound technology and is moulded for durability, terminated with solder pins to ensure reliable PCB mounting. It operates effectively across a wide temperature range of -40°C to 125°C, complying with RoHS standards and is RoHS compliant, facilitating use in environmentally-conscious applications.

The SRN1060 series is ideal for power electronics applications including DC/DC converters, notebook computers, digital video cameras, televisions, and LCD displays, where efficient power conditioning and electromagnetic shielding are critical.

The product has a maximum DC resistance of 72 mΩ and a minimum quality factor of 16, with a maximum self resonant frequency of 7 MHz ensuring stable operation in high-frequency circuits. It is supplied on a reel to cater to automated mass production processes, enhancing manufacturing efficiency.

Compact 1060 package size for dense PCB layouts. Ferrite core material for optimal magnetic performance. Semi magnetically shielded wirewound design reduces EMI. Maximum DC current rating of 3.15 A supports high power circuits.

Wide operating temperature range from -40°C to 125°C. RoHS compliant for environmentally friendly applications. Solder termination style ensures secure PCB attachment. Minimum quality factor of 16 for efficient energy storage.

Maximum self resonant frequency of 7 MHz suitable for high-frequency use. Packaged on reel for ease of automated assembly.

Used extensively in industrial electronics, telecommunications, consumer electronic devices, and power supply units, this inductor combines performance and reliability in a compact form factor.
