Wurth Elektronik Magnetically Shielded Wirewound Surface Mount Inductor 8.2 μH 4.3 A Iron Core 8030 WE-LHMI 74437356082

Wurth Elektronik 74437356082 WE-LHMI series magnetically shielded wirewound surface mount inductor features an 8.2 μH inductance with a high maximum DC current rating of 4.3 A. It is designed with an iron core and housed in a compact 8030 package suitable for surface mounting on printed circuit boards. The inductor is moulded and magnetically shielded to minimize acoustic noise and prevent leakage magnetic fields, making it ideal for sensitive electronic applications.

The device operates reliably within a temperature range of -40°C to 125°C and has an inductance tolerance of ±20 %, providing consistent electrical performance. The low maximum DC resistance of 59.3 mΩ helps reduce power loss and heat generation during operation.

This component complies with automotive standard AEC-Q200 and international standards including RoHS, IEC 61249-2-21, JEDEC JS709B, and REACH, ensuring it meets high quality and environmental requirements. The maximum self-resonant frequency of 11 MHz makes it suitable for use in high-frequency power applications.

The inductor is shipped in tape and reel packaging to facilitate automated assembly and efficient production processes. Applications include DC-DC converters for high current power supplies, power management for field programmable gate arrays (FPGA), POL converters, portable electronic devices such as PDAs and digital cameras, and mainboards or graphic cards.

This quality inductive component from Wurth Elektronik combines compact size, high current capability, and magnetic shielding to deliver reliable performance across various industrial, consumer electronics, and automotive systems.

Compact 8030 package case suitable for high current applications. Magnetically shielded design prevents leakage magnetic fields and acoustic noise. Tape & reel packaging for efficient automated assembly. Operating temperature range from -40°C to 125°C ensures durability.

Inductance tolerance of ±20 % for reliable performance. Maximum DC resistance of 59.3 mΩ reduces power loss. Compliant with automotive standard AEC-Q200 and RoHS regulations. Maximum self resonant frequency of 11 MHz for high-frequency applications.

Iron core and moulded construction enhances mechanical stability. Pin count of 2 with surface mount termination style. Explore more surface mount inductors and power Inductors at EnvMart for diverse electronic component needs.
