Eaton Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±20% 3.24 A IDC DR125-470-R
Specifications
| Country of Origin | China |
|---|---|
| Brand | Eaton |
| Height | 6mm |
| Length | 12.5mm |
| Model | DR125-470-R |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | DR |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS |
| Package/Case | 0125 |
| Maximum DC Current | 3.24A |
| Pin Count | 2 |
| Maximum DC Resistance | 74mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
Key Features
- Magnetically shielded drum core design ensures high power density and efficiency.
- Suitable for surface mount applications with 0125 package size and 2 pins.
- Maximum operating temperature of 125°C enables use in harsh environments.
- Maximum DC resistance of 74 mΩ supports low power loss and better performance.
- Ferrite core material provides reliable inductance stability and reduced electromagnetic interference.
- RoHS compliant for environmental safety and regulatory adherence.
- Designed for use in power converters including buck, boost, and resonant types.
- Applications include computers, LCD panels, DVD players, and noise filtering circuits.
Product Description
The Eaton DR125-470-R is a shielded wirewound surface mount inductor designed with a ferrite core. It provides an inductance of 47 μH with a tolerance of ±20%, capable of carrying a maximum DC current of 3.24 A, making it suited for high efficiency power management applications.
This inductor features a compact 0125 package with 2 pins and a height of 6 mm and depth of 12.5 mm, with a termination style suitable for surface mounting on printed circuit boards. The design includes magnetic shielding to minimize interference in sensitive electronics.
With a maximum operating temperature of 125°C and a maximum DC resistance of 74 mΩ, it offers reliable performance in demanding industrial environments. The core material is ferrite, molded and wirewound, supporting high power density and efficiency.
The DR series inductors such as this model are extensively used in applications like computers, DVD players, LCD panels, and various DC-DC converters including buck, boost, forward and resonant converters. It also serves well in noise filtering and choke filter configurations, improving system stability and electromagnetic compatibility.
Compliant with RoHS directives, the product meets environmental standards. Magnetically shielded drum core design for enhanced power density and efficiency. Compact 0125 surface mount package with 2-pin termination. Ferrite core material providing dependable inductance and EMI reduction.
Supports up to 3.24 A DC current with low DC resistance of 74 mΩ. Maximum operating temperature rating of 125°C for harsh conditions. RoHS compliant for environmental safety. Ideal for use in DC-DC converters, computers, LCD panels and noise filters.
Explore more from the Surface Mount Inductors category for quality electronic components suitable for industrial, laboratory, manufacturing, and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 47 μH with a tolerance of ±20%.
It can carry a maximum DC current of 3.24 A.
The maximum operating temperature is rated at 125°C.
The maximum DC resistance is 74 mΩ, which supports low power loss.
It comes in a compact 0125 package size with 2 pins.
The core material is ferrite, which provides reliable inductance stability and reduced electromagnetic interference.
This inductor is suitable for use in power converters, computers, LCD panels, DVD players, and noise filtering circuits.
The maximum self-resonant frequency is 100 kHz.
Yes, it is RoHS compliant, ensuring adherence to environmental safety regulations.
The inductor features a wirewound construction, which contributes to its performance characteristics.
The minimum operating temperature is -40°C, while the maximum is 125°C.
It has a surface mount termination style, making it suitable for mounting on printed circuit boards.
