Bourns Shielded Wirewound Surface Mount Inductor 120 μH ±10% 1.65 A Idc Ferrite Core SRR1260
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 6mm |
| Length | 12.5mm |
| Model | SRR1260 |
| Depth | 12.5mm |
| Packaging | Reel |
| Series | SRR1260 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Ferrite |
| Inductance | 120μH |
| Standards/Approvals | RoHS |
| Package/Case | 1260 |
| Maximum DC Current | 1.65A |
| Maximum DC Resistance | 210mΩ |
| Inductance Tolerance | ±10 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 5.5MHz |
| Minimum Quality Factor | 26 |
| Inductor Construction | Wirewound |
Key Features
- Designed for surface mount applications with a low profile height of 6 mm.
- Constructed with a ferrite core and wirewound inductor construction for high efficiency.
- Features magnetic shielding for reduced electromagnetic interference.
- Suitable for operating temperatures from -40°C to 125°C.
- Maximum DC resistance of 210 mΩ ensures performance stability.
- Ideal for use in DC/DC converter input/output and power supplies.
- Compliant with RoHS standards for environmental safety.
- Available in reel packaging with a 12.5 mm length and depth.
Product Description
Bourns SRR1260 shielded wirewound surface mount inductor integrates a ferrite core and wirewound construction, delivering 120 μH inductance with ±10% tolerance and a maximum DC current rating of 1.65 A. This inductor's low profile height of 6 mm and compact 12.5 mm length and depth make it suitable for space-constrained surface mount applications.
The magnetic shielding reduces electromagnetic interference, enhancing performance in sensitive electronic circuits. Its maximum DC resistance is 210 mΩ, providing efficient current handling and minimal power loss. The device operates reliably across a wide temperature range from -40°C to 125°C, making it appropriate for automotive and industrial environments.
Boasting a minimum quality factor of 26 and a maximum self-resonant frequency of 5.5 MHz, the SRR1260 is ideal for high frequency and high current applications such as DC/DC converter input/output stages and power supply circuits commonly found in portable communication equipment, camcorders, LCD TVs, and car radios.
This product complies with RoHS directives, confirming its environmental and safety standards adherence. It is offered in reel packaging for efficient handling in automated assembly processes.
Low profile height optimized for space-limited applications. Ferrite core enhances magnetic performance and efficiency. Wirewound construction provides high current capability. Shielding minimizes electromagnetic interference.
Wide operating temperature range from -40°C to 125°C. Low DC resistance of 210 mΩ for improved power efficiency. Meets RoHS environmental standards. Suitable for use in portable communication and consumer electronics. Packaged on reel for automated PCB assembly processes.
This Bourns SRR1260 inductor is a reliable choice for industrial, electronic manufacturing, automotive, and consumer electronics applications. Explore more Surface Mount Inductors and Bourns brand products through EnvMart for comprehensive engineering solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Bourns SRR1260 inductor has an inductance value of 120 μH with a tolerance of ±10%.
This model has a maximum DC current rating of 1.65 A.
The dimensions of this inductor are 6 mm in height, and it has a length and depth of 12.5 mm each.
The maximum DC resistance of the SRR1260 is 210 mΩ, ensuring performance stability.
This model operates reliably within a temperature range of -40°C to 125°C.
The SRR1260 inductor is constructed with a ferrite core, which enhances its magnetic performance.
Yes, the SRR1260 complies with RoHS standards for environmental safety.
This inductor is packaged on a reel, facilitating efficient handling in automated assembly processes.
The minimum quality factor of the SRR1260 is 26, making it suitable for high-frequency applications.
This inductor is ideal for use in DC/DC converter input/output stages and power supply circuits, particularly in portable communication equipment and consumer electronics.
The maximum self-resonant frequency of the SRR1260 is 5.5 MHz, making it suitable for high-frequency applications.
The SRR1260 features a wirewound construction, which provides high current capability and efficiency.
