Semtech 3-Element Uni-Directional TVS Diode, 100 W, 2-Pin SOD-323 UCLAMP3301D.TCT

Semtech UCLAMP3301D.TCT 3-Element Uni-Directional TVS Diode provides transient voltage suppression with a peak pulse power dissipation of 100 W in a compact surface-mount SOD-323 package. Its 2-pin uni-directional configuration makes it suitable for protecting sensitive electronics in portable devices such as mobile phones, notebooks, desktops, and servers.

This TVS diode features a minimum breakdown voltage of 3.5 V and a maximum reverse stand-off voltage of 3.3 V, clamping voltage of 9.5 V, and a peak pulse current rating of 10 A for dependable overvoltage protection. It operates efficiently over a wide temperature range from -55°C to 125°C, making it reliable for diverse environmental conditions.

The ultra-small dimensions (1.78 mm length, 1.37 mm width, 1.07 mm height) facilitate integration into compact designs while maintaining low leakage current of 500 nA. The μClamp™ series employs solid-state silicon-avalanche technology, offering excellent transient suppression including ESD to IEC 61000-4-2 standards.

This diode is ideal for industrial, consumer electronics, and telecommunication equipment requiring effective electrostatic and surge protection with minimal board space. The product is manufactured in China, containing 3 elements per chip to enhance reliability and performance.

Designed to protect data lines against ESD and electrical fast transients. Offers cable discharge event (CDE) and electrostatic discharge (ESD) protection. Compact surface-mounted package supports automated assembly and high production efficiency.

Solid-state device technology ensures fast response and long service life. Ultra-low capacitance suitable for high-speed data applications. Explore the Semtech product range and efficient TVS Diode solutions at EnvMart for enhanced circuit protection needs.
