HY Electronic Corp 60 V 3 A Surface Mount Schottky Barrier Rectifier Diode 2-Pin DO-214AC SS36A

Free Delivery in India | Lowest Global Shipping Charges

HY Electronic Corp 60 V 3 A Surface Mount Schottky Barrier Rectifier Diode 2-Pin DO-214AC SS36A

Name: HY Electronic Corp 60 V 3 A Surface Mount Schottky Barrier Rectifier Diode 2-Pin DO-214AC SS36A
Brand: HY Electronic Corp
SKU: 389068
Price: 0.07 USD
Availability: InStock



Category Diodes Brand HY Electronic Corp Condition New

Specifications

Country of Origin	China
Brand	HY Electronic Corp
Height	2.41mm
Length	4.6mm
Model	SS36A
Width	2.9mm
Mount Type	Surface
Series	FBI
Maximum Operating Temperature	150°C
Package Type	DO-214AC
Minimum Operating Temperature	-55°C
Polarity	indicated by cathode band
Pin Count	2
Maximum Continuous Forward Current If	3A
Peak Reverse Repetitive Voltage Vrrm	60V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	20mA
Peak Non-Repetitive Forward Surge Current Ifsm	80A
Maximum Forward Voltage Vf	700mV
Moulded Plastic Case (Plastic	flammability classification UL 94V-0)

Key Features

Maximum continuous forward current is rated at 3 A.
Peak reverse repetitive voltage supports up to 60 V.
Features a single diode configuration with 2 pins.
Maximum forward voltage drop is 700 mV for low power loss.
Operating temperature ranges from -55°C to 150°C.
Poised for use in free-wheeling, inverters, and polarity protection applications.
Packaged in a DO-214AC molded plastic case with UL 94V-0 flammability classification.
Polarity indicated by a cathode band for easy identification.

Product Description

HY Electronic Corp SS36A Schottky Diode DO-214AC is a high-performance surface mount schottky barrier rectifier designed for efficient electronic circuit applications. It offers a maximum continuous forward current of 3 A and peak reverse voltage of 60 V, making it suitable for power rectification tasks.

This diode features a single diode configuration with 2-pin package type DO-214AC, measuring 4.6 mm in length, 2.9 mm in width, and 2.41 mm in height. The diode exhibits a low forward voltage drop of 700 mV which improves circuit efficiency by minimizing power loss.

Operating within a temperature range of -55°C to 150°C, the SS36A diode is reliable for harsh industrial and commercial environments. Its epoxy molded plastic case complies with UL 94V-0 flammability standards, providing robust protection against heat and mechanical damage. Polarity on the diode is clearly indicated by a cathode band.

This Schottky diode is suitable for applications including free-wheeling circuits, inverter circuits, and polarity protection in electronic, industrial, and electrical equipment. Its peak non-repetitive forward surge current is 80 A, providing resilience to transient surge conditions.

Maximum continuous forward current rated at 3 A. Peak reverse repetitive voltage up to 60 V. Single diode configuration with 2-pin DO-214AC package. Maximum forward voltage drop of 700 mV for efficient rectification. Robust operating temperature range from -55°C to 150°C.

UL 94V-0 molded plastic case for high safety standards. Clear polarity marking via cathode band. Peak non-repetitive forward surge current of 80 A. This product is made in China and is new in condition. It is ideal for use in industrial and commercial electronics industries requiring reliable Schottky diode solutions.
