onsemi 2 Flip Flop IC ECL Logic Family, ECL, 3GHz Clock Frequency, Surface Mount, 20-Pin QFN MC100EP29MNG

onsemi MC100EP29MNG is a 2 Flip Flop IC designed with Emitter Coupled Logic (ECL) technology, offering high-speed digital performance in a compact 20-Pin QFN package. It supports a clock frequency of up to 3 GHz, making it suitable for demanding electronic circuits requiring rapid data synchronization and switching.

This device operates over a voltage range of 3 V minimum up to 5.5 V maximum, providing flexibility for various power supply configurations. The chip integrates 2 D Flip-Flop elements with inverting and non-inverting polarity options, enhancing design versatility for complex timing applications.

The MC100EP29MNG is mounted using surface mount technology and is engineered to withstand operating temperatures from -40°C to 85°C, crucial for robust industrial and commercial electronics environments.

Performance is further assured by a maximum propagation delay of 500 picoseconds at the specified capacitive load, ensuring minimal latency in signal processing. Physically, the device measures 4 mm in length and has a package height of 950 micrometers, facilitating integration into densely packed printed circuit boards.

Typical applications include advanced computing systems, telecommunications equipment, and laboratory instrumentation where precise flip-flop functionality and high switching speeds are essential.

Operates at a clock frequency of 3 GHz supporting high-speed digital circuits. Uses ECL logic family for emitter coupled logic performance. Surface mount 20-pin QFN package enables compact circuit designs. Operating temperature range from -40°C to 85°C ensures operational reliability.

Maximum propagation delay of 500 ps reduces timing delays. Two D Flip-Flop elements per chip provide dual storage functionality. Voltage supply range from 3 V to 5.5 V offers design flexibility. Compact size with length 4 mm and height 950 μm eases PCB layout constraints.

Suitable for industrial, laboratory, communication, and computing applications. This product is a new condition offering from onsemi, adhering to quality standards without automotive certification. Explore similar Flip Flop ICs, other Logic ICs, and high-speed ECL devices in our Electronics & Electricals semiconductor category on EnvMart.
