Texas Instruments 2 Flip Flop IC 4000 Series, 14-Pin PDIP, 3-18V Operating Voltage, 24MHz Clock Frequency CD4013BE

Texas Instruments model CD4013BE is a dual D Flip Flop integrated circuit from the 4000 series CMOS logic family designed for reliable logic operations with a wide supply voltage range of 3 to 18 volts and clock frequency up to 24MHz. The device supports single-ended inputs with inverting and non-inverting polarity and utilizes positive edge triggering, making it suitable for timing, counting, and switching tasks in electronic circuits.

This IC is mounted using a 14-pin PDIP package which allows easy through-hole soldering and integration into printed circuit boards.

The maximum propagation delay time is 90 nanoseconds, which supports efficient performance in digital logic control applications within automotive, industrial, and consumer electronics environments. It operates reliably across an extended temperature range from -55°C to 125°C.

Compact physical dimensions of length 19.3mm and height 4.57mm make the CD4013BE ideal for space-sensitive electronics projects and production usage. Wide operating voltage range: 3 to 18V. Two D flip-flops per chip enable dual-channel logic control.

Positive edge triggering for accurate timing applications. Compatible with inverting and non-inverting input polarities. Robust operating temperature range for industrial use. Standard 14-pin PDIP packaging for easy installation.

Maximum clock frequency of 24MHz suitable for moderate-speed circuits. Maximum propagation delay 90ns enhances switching speed. Compact dimensions support varied electronics design form factors.

This flip flop IC is widely used in industrial electronics, timing circuits, control systems, and other laboratory or manufacturing applications requiring reliable and precise logic switching components.
