Texas Instruments 4000 Series CMOS Logic Family 2 Flip Flop IC 14-Pin SOIC CD4013BM96

Texas Instruments CD4013BM96 is a 2 Flip Flop IC from the 4000 Series CMOS Logic Family designed for industrial and commercial semiconductor applications. It features a 14-pin SOIC package, allowing for surface mounting on PCBs while offering space-saving benefits.

This device operates over a wide supply voltage range of 3V to 18V, enabling compatibility with various electronic circuit designs. The flip-flop type is a D flip-flop with positive edge triggering, supporting both inverting and non-inverting polarity configurations, making it flexible for complex timing and data storage operations.

Operating frequencies can reach up to 24 MHz, with a maximum propagation delay time of 90 ns under 90 pF load conditions, suitable for high-speed digital logic circuits. Designed for durability, the IC supports an operating temperature range from -55°C to 125°C, covering harsh environmental conditions found in industrial and automotive electronics.

The 4000 series CMOS family is well-known for low power consumption and high noise immunity, making the CD4013BM96 ideal for battery-powered and robust applications. With two flip-flop elements integrated per chip, it reduces component count in complex logic designs and enhances reliability.

Package dimensions including a height of 1.58 mm and length of 8.65 mm provide compactness in electronic module design. The SOIC package ensures efficient heat dissipation and ease of installation.

Wide operating voltage range: 3 to 18 V. Dual D flip-flops on a single chip. Positive edge trigger for precise timing control. Surface mount 14-pin SOIC package for compact PCB layout. High maximum operating temperature of 125°C ensures reliability.

Fast switching with 24 MHz clock frequency. Low propagation delay of 90 ns for high-speed operations. Industrial and commercial use in digital electronics and semiconductor circuits.

This Texas Instruments CD4013BM96 2 Flip Flop IC is suitable for applications in digital logic, memory storage, timing circuits, and embedded system design. Its robust specifications ensure reliable performance in demanding environments. Explore more semiconductor products and electronic components in the Flip Flop ICs category on EnvMart.
