Toshiba DC Input Optocoupler Surface Mount 16-Pin SOIC TLP293-4(GB,E(T

Free Delivery in India | Lowest Global Shipping Charges

Toshiba DC Input Optocoupler Surface Mount 16-Pin SOIC TLP293-4(GB,E(T

Name: Toshiba DC Input Optocoupler Surface Mount 16-Pin SOIC TLP293-4(GB,E(T
Brand: Toshiba
SKU: 385068
Price: 1.1 USD
Availability: InStock



Category Optocoupler Brand Toshiba Condition New

Specifications

Country of Origin	Thailand
Brand	Toshiba
Model	TLP293-4(GB,E(T
Mount Type	Surface
Output type	Phototransistor
Series	TLP 293
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Maximum input current	50mA
Number Of Channels	1
Standards/Approvals	UL, CSA
Maximum Forward Voltage	1.4V
Number of Pins	16
Input Current Type	DC
Typical Rise Time	2μs
Maximum Current Transfer Ratio	600%
Typical Fall Time	3μs
Minimum Current Transfer Ratio	100%

Key Features

It uses a phototransistor output type for effective signal amplification.
The device supports a maximum forward voltage of 1.4 volts for input LED.
Typical rise and fall times are low, at 2 microseconds and 3 microseconds respectively, ensuring fast switching.
Maximum operating temperature is 125 degrees Celsius, suitable for harsh environments.
Supports a maximum input current of 50 mA, and a current transfer ratio range from 100% to 600%.
The isolation voltage is rated at 3.75 kVrms, offering strong electrical isolation.
It is compliant with UL and CSA safety standards.
The optocoupler is manufactured in Thailand and is designed for new condition industrial applications.

Product Description

Toshiba TLP293-4(GB,E(T DC Input Optocoupler is a high-performance surface mount device featuring a 16-pin SOIC package and a phototransistor output. Operating over a temperature range from -55°C to 125°C, it provides robust isolation with an isolation voltage rated at 3.75 kVrms. This optocoupler achieves fast switching speeds with typical rise and fall times of 2μs and 3μs respectively, making it suitable for industrial, electronic, and instrumentation applications requiring reliable signal transfer.

The device supports a maximum forward voltage of 1.4V and an input current of up to 50mA, with current transfer ratios ranging from 100% to 600%, enabling flexible current amplification. It complies with UL and CSA standards ensuring safety and quality. Manufactured in Thailand, this optocoupler is designed for new condition, surface-mounted applications in electronics components sectors.

Typical uses include electrical isolation in power supplies, digital interfaces, and signal couplers in automation and control systems. Its surface mount package provides efficient space utilization on PCBs. The TLP293 series combines reliable operation with compact design for diverse electronics and industrial automation needs.

Phototransistor output for effective signal transmission. Fast switching times with 2μs rise and 3μs fall times. Wide operating temperature range from -55°C to 125°C. Maximum input current of 50mA allows robust operation.

High isolation voltage of 3.75 kVrms for safety and noise immunity. Complies with UL and CSA standards for industrial quality and safety. Surface mount SOIC 16-pin package for compact PCB design. Manufactured in Thailand ensuring high-quality production standards.
