KEMET R75 Film Capacitor, ±5 % Tolerance, 220 nF, 630 V DC, 250 V AC, Through Hole Mount R75PN32204030J

KEMET R75PN32204030J is a high-quality film capacitor featuring ±5 % tolerance and 220 nF capacitance, rated for 630 V DC and 250 V AC operation. Designed for through hole mounting, it offers reliability and stability in varied electronic applications.

The capacitor utilizes metallized polypropylene film dielectric material with radial leads constructed from tinned wire. It supports high-frequency circuits at temperatures up to 105°C, encapsulated in UL94V-0 self-extinguishing material to meet stringent safety requirements.

With a lead pitch of 22.5mm and lead length of 30mm, this component is suited for secure and reliable PCB assembly. The radial design and 0.8mm lead diameter ensure precise insertion and robust mechanical integrity.

Conforming to IEC 60286-2 and RoHS standards, the R75 series capacitor maintains compliance with environmental and quality regulations. It is AEC-Q100 automotive grade certified, enabling use in automotive electronic systems requiring durability and thermal endurance.

Typical applications include deflection circuits in television displays, resonant capacitors in electronic ballasts and compact lamps, power factor correction, and coupling capacitors in switched mode power supplies (SMPS). Note that it is not suitable for across-the-line applications.

This film capacitor offers stable capacitance with low dissipation factor of 0.05%. The component is supplied packaged in bags, facilitating efficient insertion into manufacturing production lines. It features a pin count of 2 and dimensions of approximately 26.5mm length, 7mm width, and 16mm height.

KEMET’s R75PN32204030J capacitor is ideal for industrial, electronic manufacturing, automotive, and HVAC electronic applications requiring high frequency and reliability along with compliance with harsh environmental standards.
